Power Button; Circuit Breaker - SolaX Power QUICK INSTALLATION GUIDE Quick Installation Manual

Overview of Terminals
• Terminals breaker of battery
DIP
DIP
BAT+
BAT+
Right side view

Circuit breaker

8
COMM
terminal GND
BMS
BAT-
POWER
Power
BAT-
button
Left side view
• Terminals breaker of BI
20 21 22
19
1
2
3
5
6
10
9
BI power terminal (Purchased by customer)
No. Terminals Cross-sectional Area Range
12-8 AWG (3.8 KW),
INV terminals
1
10-8 AWG (5/6/7.6 KW)
2 GEN terminals
8-4 AWG
3 Load terminals 3 AWG-4/0 AWG
Grid terminals
4
3 AWG-4/0 AWG
12-8 AWG (3.8 KW),
5 INV Neutral terminals
10-8 AWG (5/6/7.6 KW)
6 GEN Neutral terminals
8-4 AWG
7 Load Neutral terminals 3 AWG-4/0 AWG
8 Main Neutral terminals
3 AWG-4/0 AWG
9 INV Ground terminals 8 AWG
10 GEN Ground terminals 8-6 AWG
11 Load Ground terminals
6-4 AWG
12 Main Ground terminals 6-4 AWG
* The type of BI power cable shall be
90°C(194°F), 600 V, copper.
Overview of Terminals
13
14
15
16 17 18
8
4
7
12
11
Strip Length Torque (in-lbs)
0.67 in / 17 mm 30
0.67 in / 17 mm /
1.25 in / 32 mm 275
1.25 in / 32 mm 275
0.79 in / 20 mm 275
0.79 in / 20 mm /
1.77 in / 45 mm 275
1.77 in / 45 mm 275
0.79 in / 20 mm 30
0.79 in / 20 mm 30
1.77 in / 45 mm 30
1.77 in / 45 mm 30
9
