SolaX Power QUICK INSTALLATION GUIDE Quick Installation Manual page 4

Packing List
Base for Battery:
Item
Name and Quantity
/ Base
4
Description
Product
• Packing list of BI
A
C D
G H I
Item Name and Quantity Description
A Backup intefaceX1 Product
B BracketX1 Support the BI to be mounted on the wall
Expansion boltX5
Four for fixing the bracket and one for fixing the BI
C
Self-tapping screwX5 Four for fixing the bracket and one for fixing the BI
D
WasherX5
E Four for fixing the bracket and one for fixing the BI
55*13*23.7mm Copper barX4
For parallel connection with inverter
F
M4*12 cross screwX1
G Fix the circuit breaker
M5*12 cross screwX8
Fix the part when parallel connection with inverter
H
40*13*7.9mm Copper barX4
I For parallel connection with inverter
Communication cableX1
J Communicate with inverter
K Warranty cardX1 For warranty registration
L
Punching reference paperX1
For hole location
M Cable tieX5
Fix the cable
Packing List
B
E F M
J L K
5
