- Page 1 Installation Manual Model 735Z 55 Gallon Automatic Preservative Applicator 735Z-24-INST-Imp&Metric 3/24...
-
Page 3: Table Of Contents
Warranty Statement Introduction Congratulations and thank you for purchasing a Harvest Tec Model 735Z applicator. Please read this manual carefully to ensure correct steps are taken to attach the applicator to the baler. This applicator is designed to apply Harvest Tec buffered propionic acid. Use of alternative products may cause complications. Including inaccurate readings from the flow meter and damage to all parts. -
Page 4: Installation Of Applicator
Installation of Applicator Installation of Mounting Brackets and Tank 1. Locate parts 001-4703ZR-A, 001-4703ZR-B, two 001-4703ZR-C and four ¾” x 4 ½” bolts, lock washers and nut. 2. Line up 001-4703ZR-A and 001-4703ZR-B about 18 inches apart on the ground. Slide part 001-4703ZR-C into square mounts and secure with ¾”... -
Page 5: Installation Of Mounting Brackets And Tank
Installation of Mounting Brackets and Tank (continued) -
Page 6: Mount Pump Plate Assembly
Mount Pump Plate Assembly Locate parts bag 8. Using two 3/8” x 1/4” bolts, locks, washers, and nuts. Mount the U-shaped pump plate mount 001-4647 (right) onto the tank saddle in the mounting holes located between the strap brackets on back of saddle (figure 7). -
Page 7: Placement Of Spray Nozzle Assembly
Placement of Spray Nozzle Assembly The cross bar on the wind guard above the pick-up head provides a mounting point for the nozzle holders (001-4714). Mount the nozzle holders on the wind guard, using the supplied U bolts (001-4714UBL). Measuring from the center of the baler, the nozzle holders will need to be 6” (15cm) apart on a 4’ (1.2M) and 9” (23cm) apart on a 5’... -
Page 8: Installation Of Moisture Sensing Pads
Note: If your baler does have a factory moisture system installed. You can use the factory moisture disc. However, you will need to disconnect the wires leading to both sensors and tape them up. You cannot have the balers moisture wires and Harvest Tec’s moisture wires connected to the moisture disc at the same time. Figure 1 2”... -
Page 9: End Of Bale Sensor
Installation of End of Bale Sensor The bale rate timer/ end of bale sensor is used to determine when the baler door is open upon bale completion. With this information the system is able to change the tons/hour automatically (see Operating Instructions, Automatic Mode). -
Page 10: Tractor Setup
Tractor Setup The general tractor setup of the 700 Series applicator can be seen above. The main harness of interest is the tractor power/communication harness (006-765IC). This harness will connect at the tractor battery, to the ISO Communication Module (ICM) mounted in the cab, a keyed power connection point, and connect at the hitch area to the baler power/communication harness (006-765B). -
Page 11: Display Options
Optional Harvest Tec Display The 700 series Harvest Tec Display will allow you to set your real time baling parameters to ensure the most precise application to every bale. This is done by utilizing the improved touch technology to select objects, enter data, and swipe through operational screens. -
Page 12: Wiring Diagram
Wiring Diagram – 731, 735Z, 737, 738K, 747, & 749 Models 1. Connect the power harness (006-765IC) to the tractor battery (12 volt) using the red wire with fuse to the positive side and the black wire to the negative. -
Page 13: Pin Outs
Pin Outs Integrated Control Module (ICM) on Tractor Harness 006-765IC (Deutsch Plug Number: DTM06-12SA) Pin 1 +12V from ECU Pin 2 Purple Signal Wire Pin 3 Red/White +12V CAN X Pin 4 Black/White Ground CAN X Pin 5 Orange CAN X Hi Pin 6 Blue CAN X Lo... - Page 14 Pin Outs (continued) Power / Communication Baler Harness 006-763B at Hitch (Deutsch Plug Number: HDP26-24-18SN) Pin 1 Not Used ---- Pin 2 Yellow ISO CAN Hi Pin 3 Green ISO CAN Lo Pin 4 +12V Power to ECU Pin 5 Black Ground to ECU Pin 6...
- Page 15 Pin Outs (continued) CAN / IDM on Baler Harness 006-763B (Deutsch Plug Number: DT06-4S) Pin 1 +12V to ECU Pin 2 Yellow ISO CAN Hi Pin 3 Green ISO CAN Lo Pin 4 Black Ground to ECU End of Bale Sensor Plug on Baler Harness 006-763B (Deutsch Plug Number: DT06-3S) Pin 1 Orange/White...
-
Page 16: Parts Breakdown
Model 735Z Base Kit Description Part # Description Part # 50 Gallon Tank 005-9203SQ Side Rail Plate 001-4703ZR-E Tank Cap, Gasket, & Breather P05-9022HBG Front Mount Support 001-4703ZR-D2 Tank Saddle 001-4703X Front Mount Crossmember 001-4703ZR-D1 Tank Strap 001-4402 Long Side Rail... - Page 17 Model Base Kit (continued) Description Part # Description Part # 50 Gallon Tank 005-9203SQ Side Rail Plate 001-4703ZR-E Tank Cap, Gasket, & Breather P05-9022HBG Front Mount Support 001-4703ZR-D2 Tank Saddle 001-4703X Front Mount Crossmember 001-4703ZR-D1 Tank Strap 001-4402 Long Side Rail 001-4703ZR-C Tank Saddle Support 001-4703ZE-G...
-
Page 18: Pump Assembly
Parts Breakdown for Pump Assembly 006-4724A 001-4647 Part# Description Part# Description 3/8”MPT X 1/2"HB Elbow 003-EL3812 003-M1212 1/2" Union 007-4120DE 300 Series Pump 002-4315-100 1/2" Line Strainer-100 Mesh 3/8” x 3/8” Union 003-M3838 003-SE12 1/2" Street Elbow 3/8” Street Elbow 003-SE38 002-2212 1/2"... -
Page 19: Control Box And Wiring Harnesses
Control Box and Wiring Harnesses Ref Description Part# Ref Description Part# Power Lead Baler 20’ 006-762B 120 Ohn Resistor 006-700R* Power Lead Tractor 006-765IC Dust Plug Kit 006-765DP Key Switch Wire 006-765CPH Lightning to USB-A Cable 006-6672USBC ISO Pump Module 006-7671RB Optional USB-C to USB-A 006-6672USBX... -
Page 20: 700 Solenoid Package
700 Pulsing Solenoid- Round Balers 1A, 1B, or 1C Solenoid Packages Ref Description Part # Description Part # Solenoid Harness (5’) 006-3650-S1 1/4" Female Disconnect 004-1207H Solenoid Harness (10’) 006-3650-S2 Solenoid 002-2203F Solenoid Harness (15’) 006-3650-S3 Solenoid Valve Body 004-1207VF #6 Hose Clamp 003-9003 1/4"... -
Page 21: Moisture Sensor
OPTIONAL High Output Solenoid (Included with 700RBHTK Kit) Ref Description Part # #6 Hose Clamp 003-9003 1/4" x 1/2" Straight Fitting 003-A1412 Female Quick Coupler 004-1207H 14 15 Rubber Washer 004-1207W Solenoid 002-2203F Solenoid Harness (10’) 006-3650-S2 1/4" Street Elbow 003-SE14 Mini Hose Clamp 003-9002... -
Page 22: Parts Bag Packages & Hoses
Parts Bag Packages & Hoses PBA-1 PBP-16 Ref Description Part # Description Part # 3/4" Ball Valve 002-2200 3/4" x 1/2" Elbow 003-EL3412 Valve Holder 001-6702H 3/4" Jiffy Clip 008-9010 Female Coupler 002-2204A #6 Hose Clamp 003-9003 Male Shut-Off Plug 002-2205G Small Jiffy Clip 008-9009... -
Page 23: Spray Shield
735Z Spray Shield Ref Description Part # Ref Description Part # U Bolt 001-4714UBS Nozzle Body 004-4722 Hose Clamp 003-9002 Tip Strainer 004-1203-100 Tip – Gray* 1/4" x 1/4" Fitting 003-A1414 004-XR11006VS 1/4" Sq Tee 003-TT14SQ Nozzle Cap 004-4723 1/4" St Elbow... -
Page 24: Optional Ipad Display Kit
Optional iPad Display Kit Description Part # iPad Mini 4 (Refurbished) 006-4670IP Complete iPad Mini Kit 030-4670DK Suction Cup Mount 001-2012SCM (Includes 1-5 and Comm. Cable) Ram Mount 001-2012H Mounting Kit Only 030-2014MK Spring Load Cradle 001-2012SLC (Includes all parts except iPad Mini 4) iPad Mini 4 Case 001-2012C4 Lightning Comm. -
Page 25: Optional Android Displaykit
Optional Android Display Kit (030-1670DK) Description Part # Suction Cup Mount 001-2012SCM Ram Mount 001-2012H Spring Load Cradle 001-2012SLC Android Case 001-2012A1 Android Tablet 006-1670AT Installation Instructions 1. Assemble Cradle (001-2012SLC) 2. Attach round base from ram mount to cradle 3. -
Page 26: Optional Ht Vt Display Kit
Installation Instructions Identify 006-765GH harness connection to 006-765IC tractor harness. 2. Connect harness to the Harvest Tec Display before tightening into place. 3. Tighten the mounting and display. Streamline harness, as necessary. 4. Once connected, power cycle system and ensure display is working properly. -
Page 27: Warranty Statement
Harvest Tec, LLC. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion. - Page 28 HARVEST TEC, LLC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 USA PHONE: 715-386-9100 FAX: 715-381-1792 Email: info@harvesttec.com...
