Summary of Contents for Harvest TEC 710
- Page 1 OWNER’S MANUAL Model 710 DEW SIMULATOR #010-710 REV 9-11...
-
Page 2: Table Of Contents
Table of Contents PAGE Assembly and Setup Pictures of Dew Simulator Unloading and Lining up the Machine Connecting the Reel Installing Auxiliary Nozzles Connecting the Hoses Installing the Tines Installing the Drive Chain Mounting the Wire Harness Preparing the Tank Operation 8-10 Check Oil Level in the Pump... -
Page 3: Pictures Of Dew Simulator
MODEL 710- DEW SIMULATOR... -
Page 4: Assembly And Setup
ASSEMBLY AND SETUP UNLOADING AND LINING UP THE MACHINE To begin assembly, you will need to use a forklift or loader to lift the reel off of the cart frame. Begin by placing a ¾” x 4” bolt with washer through the front and rear lift points with a nut and flat washer on the backside of each bolt. -
Page 5: Installing Auxiliary Nozzles
INSTALLING THE AUXILIARY NOZZLES Fasten the two nozzle holder brackets (001-7149) to the pre-drilled holes located inside of the front outer rails of the reel frame using 3/8”x3” bolts, locks, and two flat washers a piece. Screw a nipple (004-M14) into the swivel (004-4733) and then place this assembly up through the bottom side of the nozzle holder bracket. -
Page 6: Installing The Drive Chain
INSTALLING THE DRIVE CHAIN Remove the drive chain from the parts box. Begin installing the drive chain assembly by loosening and sliding up the idler sprocket. Install the drive chain and complete the installation by moving the idler down against the chain until it is tight and tighten the idler. -
Page 7: Mounting The Wire Harness
MOUNTING THE WIRE HARNESS A 7-pole wire harness is included in the parts box that is designed to go between the tractor and water trailer should you decide that you want road lights on the water trailer. The metal bracket should be mounted at the rear of the cart frame. -
Page 8: Operation
You can use the sight gauge located on the side of the pump to check the oil level. Fill the pump crankcase with approximately 4.75 quarts of pump oil from Harvest Tec (part #009-7127OIL) or until the oil has reached the top of the sight gauge. Check the oil level daily before operation by looking at the sight glass located on the side of the pump. -
Page 9: Priming
Begin by connecting the suction & return lines from the water trailer to the suction & return lines of the 710 Dew Simulator with the quick couplers. The first step of operation is priming the pump. To prime the pump, locate the brass ball valve at the rear of the pump manifold. This valve is on the discharge side of the pump. -
Page 10: Field Operation
Before disconnecting the quick coupler, close the 2” ball valve on the trailer. Disconnect the coupler and connect to the fill source. Harvest Tec recommends that you have an inline screen on your fill source. Open the ball valve and begin filling. When filling is completed, shut off the fill source and close the 2”... -
Page 11: Application Rates
APPLICATION RATES SOFTENING AGENT The Harvest Tec 710 Dew Simulator is designed to add moisture to windrowed hay with the aid of a chemical softening agent mixed with water. This confidentially formulated chemical, HS2002, has a silicone base and is designed to help the water added soak into the hay more completely and quicker. -
Page 12: Application Rate Tables
APPLICATION RATE TABLES * Determine what ground speed you want to go. It works well to choose a ground speed that is comparable to the ground speed at which you’ll be baling at. * After determining the Acres/Hr to be covered, find how many Tons/ Hr you will be doing. * Cross reference the Ton/Hr you with the estimated pretreated moisture content to get the number of (Gal/Hr) you will need to apply. -
Page 13: Application Rate Example
Valve Trip Position Rear Trip Front Trip -Position 1-5 -Position A-E APPLICATION RATE EXAMPLE If you have a 30-foot swath raked together and estimate that the hay is 8% moisture, what setting would you use if you estimated the crop would go 1-1/2 ton/acre at 15% moisture and you wanted to travel at 6 mph? Given this information, begin by looking in Table 1 to determine how many acres/hour you would be covering. -
Page 14: Trouble Shooting
TROUBLE SHOOTING PUMP WILL NOT PRIME Check that the bypass valve is open, the strainer is clean, and the valve on trailer is open The pump should now circulate water back to the tank when the bypass valve is open. A dirty strainer will result in reduced flow that leads to a lack of pressure. -
Page 15: Parts Breakdown- Hardware, Oil, Chain, And Wiring
Parts Breakdown – Hardware, Oil, Chain, and Wiring Harness Ref # Description Part # Roller chain #50 008-7142 5 ft Roller chain splice #50 008-7142A Roller chain splice #50 008-7142B Zinc roll pin 001-7144 Thrust bushing – 1/16” thickness 008-7146A ¾”X 2”... -
Page 16: Parts Breakdown- Bag And Auxiliary Nozzle Placement
Parts Breakdown-Parts Bag and Auxiliary Nozzle Assembly Ref # Description Part # Ref # Description Part # Aux. Nozzle mounts 001-7149 #6 hose clamp 003-9003 3/8” nuts Swivel body 004-4733 3/8” lock washers ¾” cam coupler 002-2204D 3/8” washers Nozzle caps 004-4723 3/8”... -
Page 17: Parts Breakdown- Gauges & Ball Valve Assembly
Parts Breakdown-Gauges and Ball Valve Assembly Ref # Description Part # GAUGE 0-5000 PSI 002-7136 4” GAUGE 100 PSI 002-2208Z 2” STRAIGHT FITTING 003-A2020 2” VALVE 002-2220 CAM COUPLER 2”MPT 002-2204I... -
Page 18: Parts Breakdown- Drive Line Assembly
Drive Line Assembly Ref # Description Part # Idler sprocket 001-7125 Collar 001-7150 Drive sprocket 001-7124B Four bolt bearing 008-7137 Rim bolts 008-7130B... -
Page 19: Parts Breakdown- Hose & Hose Couplers
Parts Breakdown-Hose and Hose Couplers Ref # Description Part # Ribbed hose-2” 002-9004 EVA hose-3/4” 002-9002 EVA hose-1/2” 002-9001 Hydraulic hose-12’ 002-9712 High pressure water hose 11’ 002-9713 Hydraulic hose-11’ 002-9714 ¾” cam plug 002-2205G ¾” female cam coupler 002-2204F 2”... -
Page 20: Parts Breakdown- Cross Tube Assembly & Pto Shaft & Hydraulic Ram
Parts Breakdown- Cross Tube Assembly & PTO Shaft and Hydraulic Ram Ref # Description Part # Brass standoff 3/8” 001-7105A Brass standoff 1 1/2” 001-7105B Brass standoff 2 5/8” 001-7105C Brass standoff 3 3/4” 001-7105D Six tine cross tube 001-7106 Seven time cross tube 001-7107 Cross tube bearing insert... -
Page 21: Parts Breakdown- Valve Assembly
Parts Breakdown- Valve Assembly Ref # Description Part # Valve to cross tube hose 002-7104B Valve actuator 001-7104VA Valve actuator support plate 001-7104VB Valve actuator stop pin 001-7104VC Valve block 001-7104VD Flow pin 001-7104VE Ball 001-7104VF Spring 001-7104VG Spring retainer 001-7104VH Hub to valve hose 002-7104A... -
Page 22: Parts Breakdown- High & Low Pressure Manifold
Parts Breakdown-High and Low Pressure Manifold Ref # Description Part # Ref # Description Part # Elbow-3/4”HBX11/2”MPT 003-EL11234 Knob 002-7135K Tee-11/2” 003-TT112 Adjustable relief valve 002-7137 Straight-2”HBX11/2”MPT 003-A20112 Needle valve 002-7134 Filter bowl 002-4319F 003-DSHA1212 45 hyd. swivel Nipple-11/2”MPT 003-M112112 Straight fitting-1/2”... -
Page 23: Parts Breakdown- Tires, Rims And Frame
Parts Breakdown- Tires, Rims and Frame... - Page 24 Ref # Description Part # Cart frame 001-7120 Clevis hitch 001-7119 Reel frame 001-7118 Wrap guard 001-7117 Wheel extension 001-7120RXT Reel bracing arm 001-7111 Jack 5000# 008-7133 Cart frame tire 008-7140 Cart frame rim 008-7131 Reel frame tire 008-7139 Reel frame rim 008-7130 Pump 007-7127...
-
Page 25: Notes
NOTES:... -
Page 26: Warranty And Liability Agreement
Harvest Tec, Inc. within 30 days of the failure. Parts must be returned through the selling dealer and distributor, transportation charges prepaid. - Page 27 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
