Harvest TEC 600BB Operation Manual

Moisture sensor kit for large square balers
Hide thumbs Also See for 600BB:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Operation Manual
Moisture Sensor Kit for Large Square Balers
For New Holland BigBaler and Case IH LB 4
600BB-17-M-OPR
12/17
Forage Harvester
Model 600BB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 600BB and is the answer not in the manual?

Questions and answers

Related Manuals for Harvest TEC 600BB

Summary of Contents for Harvest TEC 600BB

  • Page 1 Operation Manual Model 600BB Moisture Sensor Kit for Large Square Balers For New Holland BigBaler and Case IH LB 4 Forage Harvester 600BB-17-M-OPR 12/17...
  • Page 2 Council of 17 May 2006 and other applicable European Directives including Directive 2004/108/EC on the Electromagnetic compatability. The application of preservatives for hay Harvest Tec system will be turned on after being installed on a farm press has been declard in conformity with the Machinery Directive.

  • Page 3: Table Of Contents

    Safety Decals Connecting Power and Communications Harness Communicating through the ISOBUS Monitor 6-14 Operation of the ISOBUS Monitor 15-23 Description of Screens and Menus of the Harvest Tec Monitor Operating Instructions Automatic Mode Description of Additional Screens and Menus 17-19 Diagnostics...

  • Page 4: Introduction

    Introduction Thank you for purchasing this 600BB Moisture Sensor Kit. The 600BB Moisture Sensor Kit is designed to operator through the baler’s ISOBUS system and/or an Apple iPad (not included) using the Hay App. The 600BB Moisture Sensor offers these advantages: 1.

  • Page 5: Safety

    Safety Carefully read all the safety signs in this manual and on the applicator before use. Keep signs clean and in good working order. Replace missing or damaged safety signs. Replacement signs are available from your local authorized dealer. Keep your applicator in proper working condition. Unauthorized modifications to the applicator may impair the function and/or safety of the machine.

  • Page 6: Communicating Through The Isobus Monitor

    Communicating through the ISOBUS Monitor to Utilize the Moisture Sensor Kit When the 600 Series processor is connected to the baler and powered on the first time it is necessary to load the object pools to the Virtual Terminal (VT). Icon (1) indicates that the object pools are in the process of loading and saving to the VT.
  • Page 7 After verifying that the 600 Series object pool is loaded and the 600 Series System operating screens are displayed on the VT, press the NEXT IMPLEMENT button (3) to return to the baler work screen page. Press the bottom button of the Menu Bar with the down arrow in corner (4) on the side of the screen to continue down the Menu Bar below the USER SETTING icon.
  • Page 8 4 .2 .0 .0 Scroll through the Menu bar until the INFORMATION icon (5) is visible. Press the INFORMATION button so the Information page appears. Verify that the controller software loaded to the baler is version 4.2.0.0 or higher. If not, contact the dealer to update firmware in Baler Control Module (BCM). If the controller software displays version 4.2.0.0 or higher proceed, to configuring the baler for the 600 Series System by pressing the MACHINE SETUP button (6).
  • Page 9 The second page of the Machine setup screens is identified by the three light gray buttons in the Menu Bar. Press and hold second light gray button (8) for 10 seconds or until display switches to displaying Dealer Mode. Once Dealer Mode has been entered, select the down arrow in the Menu Bar (9) to scroll to the second Dealer Mode Screen where ‘Moisture’...
  • Page 10 Once you have reached the second Dealer Mode screen, select the area under ‘Moisture‘(10). Note that the box below ‘Moisture’ will likely be the default “NOT INSTALLED”. Select the proper configuration setting from the pop up menu (11), based on the configuration of your 600 Series system.
  • Page 11 Once the configuration has been set press the MACHINE SETUP icon (12) to return to the Machine Setup Screen and the Menu Bar. Press the arrow down button at the bottom of the Menu Bar (13) to scroll down thru the Menu Bar until you reach the SCREEN SETUP pages.
  • Page 12 Select the icon for SCREEN SETUP 1 (14) so the Screen Setup 1 screen appears. Select how you would like to have the screen configured to show a combination of baler and 600 Series system information by selecting the boxes. When you select one of the boxes, a popup screen will appear that shows the selections available. Selections related to the 600 Series system include Moisture and Moisture Bale.
  • Page 13 Once the Screen Setup pages have been configured, scroll back up to the top of the Menu Bar by pressing the top button in the Menu Bar with the up arrow (16). Select the FIELD SETTING icon (17) and adjust the Moisture Alarm Settings in the Field Setting Screen. Note that the low moisture alarm must be set lower than the high moisture alarm.
  • Page 14 Baler Work Screen and the 600 Series System Work Screen by pressing the NEXT IMPLEMENT button (19) during operation. Harvest Tec Icons signified by arrows 19-25 are listed below. 19, 20, 21, and 24 are visible with the Moisture Only 600BB System. All would be visible with a complete applicator system.

  • Page 15: Operation Of The Isobus Monitor

    Operation of the ISOBUS Monitor Description of Screens and Menus of the ISOBUS Monitor All Buttons are color coded and labeled. Selections can be made by touching the actual screen choice or by touching the numbers down the right side menu which are color and numerically coded to correlate with the same selection.

  • Page 16: Operating Instructions

    Operating Instructions Automatic Mode will be used in the field to read both hay moisture content sensed by the star wheels and the operator’s preset parameters to determine baling rate and tons per hour. Automatic Mode (or Manual Mode) After pushing the AUTOMATIC MODE key in the MAIN MENU screen, the following screen should appear: 1.

  • Page 17: Description Of Additional Screens And Menus

    The following pages provide additional screen functionality you may choose to use if you add preservative and or the tagging capabilities. Description of Additional Screens and Menus Use the below listed screen menus to navigate through all of the operation screens. Navigation through the screens is accomplished by using the touch screen and pressing the appropriate function.

  • Page 18: Setup Mode

    Setup Mode:...

  • Page 19: Job Records

    Job Records:...

  • Page 20: Setting Up Bale Parameters For Initial Use

    Setting Up Bale Parameters for Initial Use In the SETUP MODE you will set your initial baling rate. Baling Rate Setup After pushing the SETUP MODE key in the MAIN MENU screen, the top screen should appear: 1. On this screen the operator will Select the BALING RATE SETUP (1) key. 2.

  • Page 21: Operating Instructions For Additional Screens

    Operating Instructions for Additional Screens Diagnostics After pressing the DIAGNOSTICS key in the MAIN MENU screen, the screen on the left should appear: 1. To set date and time select the Set Date/Time (1) key. In the next screen enter the date (month, day, year format) followed by the time.

  • Page 22: Job Records

    Job Records After pushing the JOB RECORDS key in the MAIN MENU screen, the upper left screen below should appear: 1. Selecting New Job (1) will save all the previous bale records and open the Field Name (2) screen. 2. Use the key pad in the Field Name screen to enter up to an eight character field name. Use the asterisk key to move on to the next letter or number if they are identical.
  • Page 23 Continued Job Records 5. Selecting the Download (9) key will open the Download Job Records screen. This screen lets you select jobs to download onto a USB drive. To download job records insert a USB drive into the port on the Dual Channel Processor.

  • Page 24: Wiring Diagram

    Wiring Diagram A. The Baler Power/Communication Harness (006-6650LS(E)) will attach to the open port of the Tractor Harness (006-6650TM(E)) and run back to the Dual Channel Processor (006-6671LS(E)). B. Connect the large plug of the Baler Power/Communication Harness (006-6650LS) to the bottom (shorter side) of the DCP.

  • Page 25: Pin Outs

    Pin Outs Power/Comm Harness 006-6650TM(E) at Hitch Pin 1 Red +12V Power to TSD Pin 2 Red +12V Power to DCP Pin 3 Orange Keyed Power Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Orange Can1 Hi Pin 8 Black...
  • Page 26 Pin Outs (continued) 006-6650VA to 006-6650LS(E) Pin 1 Red Can Power Pin 2 Black Can Ground Pin 3 Yellow HT Can Hi Pin 4 Gray Shield Pin 5 Green HT Can Low Pin 6 N/A Pin 7 N/A 006-6650VA Harness to Baler Plug Pin A N/A Pin B Red TBC Power...

  • Page 27: Maintenance

    Maintenance If you are unsure how to perform any of the maintenance steps have your local authorized dealer perform the tasks. Dielectric Grease Connections: Disconnect all harnesses on the applicator, clean the connections, and repack with dielectric grease. Battery Connections: Follow the batteries safety warnings and clean the battery connections. If the connections cannot be cleaned, replace harness.

  • Page 28: Troubleshooting

    5. Short in wire between star 5. Replace wire. wheels and DCP. 6. Check hay with hand tester 6. Contact Harvest Tec if conditions to verify. persist. Moisture readings erratic. 1. Test bales with hand tester to verify that DCP has more variation than hand tester.

  • Page 29: Parts Breakdown

    Parts Breakdown 600BB Series Controls and Harnesses Dual Channel Processor (DCP) Ref Description Part Number End of Bale Sensor 600 Series 006-7400 End of Bale Sensor Bracket 001-4648 Terminating Connector 600 Series w/green cap 006-5650Z DCP Shield/Cover 001-5650X DCP Main Control LS 600 AUTO...
  • Page 30 Parts Breakdown for Star Wheel Moisture Sensor And Bale Rate Sensors Ref Description Part Number Qty Description Part Number Qty Block cover 006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left 001-4645 Snap ring (per side) 006-4641K...

  • Page 31: Optional Ipad Mini Mounting Kit

    Optional iPad Mini Mounting Kit (030-2014MK) Description Part # Suction cup mount 001-2012SCM Ram mount 001-2012H iPad Mini spring load cradle (Mini 1,2,3) 001-2012SLC 16 gauge power wire 006-4723P Female spade connector Hardware Eye loop connector Hardware iPad Mini Charger 12V 001-2012P iPad Mini 4 case 001-2012C4...

  • Page 32: Optional Ipad Display Kit

    Optional iPad Display Kit (030-4670DK) Description Part # Ref Description Part # Suction cup mount 001-2012SCM iPad Mini Charger 12V 001-2012P Ram mount 001-2012H iPad Mini 4 case 001-2012C4 iPad Mini spring load 001-2012SLC iPad Mini 4 006-4670IP cradle (Mini 1,2,3) 16 gauge power wire 006-4723P 4 amp fuse...

  • Page 33: Notes

    Notes...
  • Page 34 Notes...

  • Page 35: Warranty Statement

    Harvest Tec, Inc. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion.
  • Page 36 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
