- Page 1 Installation Manual Model 300SS Moisture Only Kit for Small Square Balers Forage Harvester 300SS-16-INST 4/18...
- Page 2 (intentionally blank)
-
Page 3: Table Of Contents
300SS Installation Manual Table of Contents Page Introduction System Requirements Tools Needed Bluetooth Receiver Lights Installation of the 300SS Installation of Three Hundred Series (THS) controller Installation of the End of Bale Sensors Installation of Star Wheels Wiring Diagram Pin Outs... -
Page 4: Introduction
Introduction Congratulations and thank you for purchasing a Harvest Tec Model 300SS moisture only kit. Please read this manual carefully to ensure correct steps are taken to attach the system to the baler. This applicator is designed to read moisture through an Apple iPad. A parts break of the system is located in the back of the manual. -
Page 5: Installation Of The 300Ss
Installation of the 300SS Locate the controls package. Select a mounting location for the Three Hundred Series (THS) control box (006- 3671SS) easily accessible that is away from moving parts and access panels. Check before drilling to ensure nothing will be damaged on the opposite side of the THS. After selecting the location for the THS, use the THS as a drill guide and mark the four mounting holes. -
Page 6: Installation Of The End Of Bale Sensors
Installation of End of Bale Sensor Mount the 006-7400 sensor to the mounting bracket 001-4648SI for AGCO as shown below (Figure 1). Case IH, New Holland, & John Deere and other balers will use bracket 001-4648SS. Mount the assembly on the right side of the baler chamber. -
Page 7: Wiring Diagram
The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. CONTACT HARVEST TEC BEFORE MODIFICATIONS. b. This unit will not function on positive ground tractors. -
Page 8: Pin Outs
Pin Outs Power Harness 006-3650T at Tractor Hitch Pin 1 Red +12V Power to BLE Pin 2 Red +12V Power to THS Pin 3 Orange Keyed Power Pin 4 Not Used Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Not Used Pin 8 Black... - Page 9 Pin Outs (continued) End of Row Sensor at 300 Controller Harness Pin 1 Red/White +12V Power Pin 2 Black/White Ground Pin 3 Yellow Signal Pin 4 N/A Moisture Sensor connection at 300 Controller Harness Pin 1 Not Used Pin 2 Not Used Pin 3 Not Used Pin 4 Not Used Pin 5 Not Used...
-
Page 10: Parts Breakdown
Control Box and Wiring Harnesses 1 or 7 Ref Description Part# Ref Description Part# Power lead baler 20’ 006-3650B1 300 Series Controller 006-3671SS Power lead tractor 006-3650T Dust Plugs 006-5651Plugs Power lead baler 30’ (AGCO) Key Switch Wire 006-5650K 006-3650B2 Bluetooth Receiver 006-6672A Complete Assembly (1-6) -
Page 11: Star Wheels Sensors, Moisture Harness
Star Wheel Sensors Description Part# Washer (per side) 006-4642K Dust Seal (per side) w/006-4642K Snap Ring (per side) w/006-4642K Swivel 006-4642A Star Wheel 030-4641E Insert w/ Ref # 5 Wiring grommet 008-0821A Star wheel block 006-4641A Plug Fitting 003-F38 Block Cover 006-4641B 1-10 Star wheel assembly... -
Page 12: Optional Ipad Mini Mounting Kit (030-2014Mk)
Optional iPad Mini Mounting Kit (030-2014MK) Description Part # Suction cup mount 001-2012SCM Ram mount 001-2012H iPad Mini spring load cradle (Mini 2) 001-2012SLC 16 gauge power wire 006-4723P Female spade connector Hardware Eye loop connector Hardware iPad Mini Charger 12V 001-2012P iPad Mini 4 case 001-2012C4... -
Page 13: Optional Ipad Display Kit (030-4670Dk)
Optional iPad Display Kit (030-4670DK) Description Part # Ref Description Part # Suction cup mount 001-2012SCM iPad Mini Charger 12V 001-2012P Ram mount 001-2012H iPad Mini 4 case 001-2012C4 iPad Mini spring load 001-2012SLC iPad Mini 4 006-4670IP cradle (Mini 4) 16 gauge power wire 006-4723P 4 amp fuse... -
Page 14: Notes
Notes... -
Page 15: Warranty Statement
Harvest Tec, Inc. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion. - Page 16 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
