- Page 1 Installation Manual Model 300RB & 300RBC Moisture Only Kit for Round Balers Forage Harvester 300RB & 300RBC-16-INST 4/18...
- Page 2 (intentionally blank)
-
Page 3: Table Of Contents
300RB Installation Manual Table of Contents Page Introduction System Requirements Tools Needed Bluetooth Receiver Lights Installation of 300RB & 300RBC 5-16 Installation of Control - 300 RB Installation of Control - 300RBC Installation of Moisture Sensor Pads 7-16 Four Foot Wide Balers... -
Page 4: Introduction
Introduction Congratulations and thank you for purchasing a Harvest Tec Model 300RB or the 300RBC moisture only kit. Please read this manual carefully to ensure correct steps are taken to attach the system to the baler. This applicator is designed to read moisture through an Apple iPad. A parts break of the system is located in the back of the manual. -
Page 5: Installation Of 300Rb & 300Rbc
Installation of Control - 300RB Locate the controls package. Select a mounting location for the Three Hundred Series (THS) control box (006- 3671RB) easily accessible that is away from moving parts and access panels. Check before drilling to ensure nothing will be damaged on the opposite side of the THS, some locations will be underneath baler doors. After selecting the location for the THS, use the THS as a drill guide and mark the four mounting holes. -
Page 6: Installation Of Control - 300Rbc
3. Locate the controls package. Mount the 300RB control box to the 001-4703XE bracket as shown in figure 3. You may need to drill 3/16” holes on the plate to mount controller. Use the supplied 10/32 x 3/4" Phillips flathead machine screws, nylock washers and nuts to mount the control box. -
Page 7: Installation Of Moisture Sensor Pads
Installation of Moisture Sensing Pads Four foot wide CNH balers (Pre 2015) Figure 1 2” from back of chamber (51mm) 1” from top of roll (25mm) 1. If your baler is equipped with bale shaping pads, remove disc and use existing hole that will need to be drilled to 3/4”... -
Page 8: Five Foot Wide Balers
Installation of Moisture Sensing Pads (continued) Five foot wide CNH balers (Pre 2015) Figure 1 2” from back of chamber (51mm) 1” from top of roll (25mm) 1. If your baler is equipped with bale shaping pads, remove disc and use existing that will need to be drilled to 3/4"... -
Page 9: John Deere 582
Install for John Deere 582 Figure 2 Figure 1 1. The moisture discs (006-4641H) will both need to be cut on line A. (Figure 1) One disc will need to be cut on line B and one disc on line C. 2. -
Page 10: John Deere 854
Install for John Deere 854 Figure 2 Figure 1 Figure 10 1. The moisture discs (006-4641H) will both need to be cut on line A (Figure 1). One disc will need to be cut on line B and one disc on line C. 2. -
Page 11: John Deere Round Balers
Install for John Deere Round Balers Figure 2 1/4" in from back of baler (7mm) 1” from Bottom (25mm) Figure 1 1. Both moisture discs (006-4641H) will need to be cut along the serrated line (A) shown on Figure 1. Only cut on the line shown on Figure 1, do not cut the other line. -
Page 12: Vermeer Balers
Install for Vermeer Balers Figure 1 2” from back of chamber (51mm) 1” from top of roll (25mm) 1. If your baler is equipped with bale shaping pads, remove disc and use existing hole (may need to be drilled larger, 3/4" (19mm) to install new moisture sensing discs. 2. -
Page 13: Agco Baler Models
Install for AGCO, Challenger, Massey Ferguson, New Idea 1. If your baler is equipped with bale shaping pads, remove pads and use existing hole (may need to be drilled larger) to install new moisture sensing discs. 2. If your baler is not equipped with bale shaping pads you will need to drill a hole in the chamber directly behind and above the starting roll (Figure 1). - Page 14 AGCO & Massey Ferguson (2800/2900 Series) Challenger (3 Series/RB56C/RB56CA) Figure 2 Figure 1 1. Both moisture discs (006-4641H) will need to be cut along the serrated line (A). (Figure 1) Measure from the laser etched line (B) 1.75 inches on both side. Mark and cut the disc. A completed disc in shown above (D).
-
Page 15: Rollbelt Baler - 300Rbc
Installation of Moisture Sensing Pads – 300RBC 1. Open rear tail gate of baler and lock in the up position. Refer to baler manual to lock door open. 2. Remove bale shaping discs on each side of chamber by grinding welds. Once removed grind any remaining welds so sides of bale chamber are smooth. -
Page 16: Installation Of Bale Rate Sensor
Installation of Moisture Sensor Pads and Disks - 300RBC (continued) USR (under-shot rotor) OSR (over-shot) rotor) Installation of Bale Rate Timer Sensor The bale rate timer sensor is used to determine when the baler door is open. With this information the system is able to change the tons/hour automatically. -
Page 17: Wiring Diagram - 300Rb
The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. CONTACT HARVEST TEC BEFORE MODIFICATIONS. b. This unit will not function on positive ground tractors. -
Page 18: Wiring Diagram - 300Rbc
The power harness must be connected to the battery! The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty. CONTACT HARVEST TEC BEFORE MODIFICATIONS. b. This unit will not function on positive ground tractors. -
Page 19: Pin Outs
Pin Outs Power Harness 006-3650T at Tractor Hitch Pin 1 Red +12V Power to BLE Pin 2 Red +12V Power to THS Pin 3 Orange Keyed Power Pin 4 Not Used Pin 5 Green HT Can Low Pin 6 Yellow HT Can Hi Pin 7 Not Used Pin 8 Black... - Page 20 Pin Outs (continued) End of Row Sensor at 300 Controller Harness Pin 1 Red/White +12V Power Pin 2 Black/White Ground Pin 3 Yellow Signal Pin 4 N/A Moisture Sensor connection at 300 Controller Harness Pin 1 Not Used Pin 2 Not Used Pin 3 Not Used Pin 4 Not Used Pin 5 Not Used...
-
Page 21: Parts Breakdown
Control Box and Wiring Harnesses Description Part # Tractor Power Harness 006-3650T Bluetooth Receiver 006-6672 Baler Power Harness (20’) 006-3650B1 Control Box 006-3671RB Dust Plug Kit 006-5651Plug Key Switch Harness 006-5650K Complete Assembly 030-363CPA End of Bale Sensor Kit A Ref Description Part # End of Bale Sensor... -
Page 22: Moisture Pads
Moisture Sensors – 300RB Description Part # Description Part # Plastic Pad 006-4641F Plastic Isolator 006-4641I 1/2X4 1/2” Carriage Bolt Moisture Disc 006-4641H Plastic Bushing 006-4641G Moisture Cable 006-4640G2 Moisture Pad Assembly (Ref 1-5) 030-4643 Complete Assembly (Ref 1-6) MSH-RB-A Moisture Sensor –... -
Page 23: Optional Ipad Mini Mounting Kit (030-2014Mk)
Optional iPad Mini Mounting Kit (030-2014MK) Description Part # Suction cup mount 001-2012SCM Ram mount 001-2012H iPad Mini spring load cradle (Mini 1,2,3) 001-2012SLC 16 gauge power wire 006-4723P Female spade connector Hardware Eye loop connector Hardware iPad Mini Charger 12V 001-2012P iPad Mini 4 case 001-2012C4... -
Page 24: Optional Ipad Display Kit (030-4670Dk)
Optional iPad Display Kit (030-2670DK) Description Part # Ref Description Part # Suction cup mount 001-2012SCM iPad Mini Charger 12V 001-2012P Ram mount 001-2012H iPad Mini 4 case 001-2012C4 iPad Mini spring load 001-2012SLC iPad Mini 4 006-4670IP cradle (Mini 4) 16 gauge power wire 006-4723P 4 amp fuse... -
Page 25: Notes
Notes... - Page 26 Notes...
-
Page 27: Warranty
Harvest Tec, Inc. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion. - Page 28 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
