Harvest TEC 7674552C Installation Manual

55 gallon automatic preservative applicator for grady twinpak balers

Advertisement

Quick Links

Installation Manual
Model 7674552C
55 gallon Automatic Preservative Applicator
For Grady TwinPak Balers
Forage Harvester
767-25-INST-Imp&Metric
2/25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7674552C and is the answer not in the manual?

Questions and answers

Summary of Contents for Harvest TEC 7674552C

  • Page 1 Installation Manual Model 7674552C 55 gallon Automatic Preservative Applicator For Grady TwinPak Balers Forage Harvester 767-25-INST-Imp&Metric 2/25...
  • Page 2: Table Of Contents

    Table of Contents Page Introduction, Model Reference, & Tools Needed Tank Mounting Tank Saddle Kit Breakdown Installation Pump Plate Breakdown Pump Plate Assembly Installation Mounting Control Box Drain Fill Kit and Tank Plumbing SMV, Light & Camera Bracket Parts Bags and Hosing Spray Shield Assembly Plumbing and Solenoid 10-11...
  • Page 3: Introduction, Model Reference, & Tools Needed

    Read this manual carefully to ensure correct steps are done to attach the applicator to the baler. This applicator is designed to apply Harvest Tec buffered propionic acid. Use of alternative products may cause complications and voids warranty. Complications may include inaccurate readings from the flow meter and damage to system components.
  • Page 4: Tank Mounting

    Parts Breakdown - Model 767, 467 Base Kits Tank Saddle Kit 030-0467-TK Ref# Description Part # Ref# Description Part # Tank 005-9203SQ Tank Base Assembly 001-4703XTP Tank Lid 005-9022H Strap Bracket 001-4703CD Tank Fitting 005-9100 Tank Base Foot 001-4703XTG Tank Strap 001-4402C Pump Plate Bracket 001-4647MT...
  • Page 5: Tank Installation

    Tank Saddle Kit (030-0467-TK) Installation – Tank Brackets Locate the square tube between the marker lights. Remove the existing bracketry that holds the SMV sign, light, and camera mounts. Install the Tank Base Assembly Bracket (001-4703XTP) on the rear of the baler so the formed angle on the bottom of the bracket sits on the square tube between the marker lights.
  • Page 6: Pump Plate Breakdown

    Parts Breakdown for Pump Assembly 006-4724A 001-4648X Part# Description Part# Description 003-EL3812 3/8”MPT X 1/2"HB Elbow 003-M1212 1/2" Union 007-4120DE 700/300 Series Pump 002-4315-100 1/2" Line Strainer-100 Mesh 003-M3838 3/8” x 3/8” Union 003-SE12 1/2" Street Elbow 003-SE38 3/8” Street Elbow 002-2212 1/2"...
  • Page 7: Pump Plate Assembly Installation

    Pump Plate Assembly (PMP-7636P) Installation Install the Pump Plate Assembly (PMP-7636P) to front side of Mounting Bracket (PMP-4647MT) using the lower set of holes in the bracket, aligning the slots in pump plate shield (001-4648X) with the 7/16” holes in the mounting bracket (001-4547). Center the pump plate assembly and secure using 2x 3/8-16 x 1”...
  • Page 8: Parts Bags And Hosing

    Parts Bag Packages and Hosing PBA-1 PBP-16 Ref Description Part # Description Part # 3/4" Ball Valve 002-2200 Valve Decal DCL-8004 Valve Holder 001-6702H Hazard Decal DCL-8001 Female Coupler 002-2204A 3/4" x 1/2" Elbow 003-EL3412 Male Shut-Off Plug 002-2205G 3/4" Jiffy Clip 008-9010 3/4”...
  • Page 9: Spray Shield Assembly

    Spray Shield Assembly (030-4552C) Installation Locate the round tube connecting the two sides above the rotor. Install Spray Shield Holder (001-4435T) to the front side of the round pipe with the two supplied U-bolts. Position the holder horizontal, facing the u-bolts, and attach so parallel with the ground.
  • Page 10: Plumbing And Solenoid

    See breakdown for cleaning instructions. Components are compatible with Harvest Tec Buffered Propionic Preservative and use of other products may cause an increased need for service or replacement.
  • Page 11: Solenoid Breakdown

    700 Pulsing Solenoid Breakdown – Small & Round Balers 1A, 1B, or 1C Ref Description Part # Description Part # Solenoid Harness (5’) 006-3650-S1 1/4" Female Disconnect 004-1207H Solenoid Harness (10’) 006-3650-S2 Solenoid 002-2203F Solenoid Harness (15’) 006-3650-S3 Solenoid Valve Body 004-1207VF #6 Hose Clamp 003-9003...
  • Page 12: End Of Bale Sensor (Eob)

    End of Bale (EOB) Bracket and Sensor Installation – 767 Applicator Locate the End of Bale bracket (001-4648TE) from the kit and install EOB Sensor (006-7401) centered in the EOB bracket. Locate the factory tie sensor on the RH side of the baler. Remove the nuts that secure the factory tie sensor bracket to the frame and install the EOB bracket using the factory bolts on the outside of the factory sensor.
  • Page 13: Flake/Stroke Count Sensor

    Flake/Stroke Count Sensor and Bracket (001-4648TF) Installation Locate the upper haydog on the RH side of the bale chamber and the two factory bolts holding flat steel below the plunger roller. Remove factory nuts and place the Flake Count Bracket (001-4648TF) on the underside of the flange.
  • Page 14: Star Wheel Breakdown And Moisture Harness

    Star Wheel Sensors- 700 Series 6A or 6B Description Part# Description Part# Star Wheel 006-4642US Star Wheel Nut 006-4642U Dust Seal Gasket 006-4642UG Swivel Insert 006-4642B Star Wheel Block 006-4642UB Encoder Mount 006-4512P (Avail. in 2024 Style Only) 3/8” Wire Grommet 008-0821A Encoder 006-4512E...
  • Page 15: Main Wire Harness And Connections

    Main Wire Harness and Connections Route harness (006-762B) along the left hand side of the baler. Keep harnesses away from moving parts and hydraulic hoses. Secure with existing cable clamps or use cable ties. Once all connections are made on the harness, connect to the IPM module and secure all harness wires.
  • Page 16: Tractor Setup

    Tractor Setup The general tractor setup of the 700 Series applicator can be seen above. The main harness of interest is the tractor power/communication harness (006-765IC). This harness will connect at the tractor battery, to the ISO Communication Module (ICM) mounted in the cab, a keyed power connection point, and connect at the hitch area to the baler power/communication harness (006-765B).
  • Page 17: Display Options

    Optional Harvest Tec Display The 700 series Harvest Tec Display will allow you to set your real time baling parameters to ensure the most precise application to every bale. This is done by utilizing the improved touch technology to select objects, enter data, and swipe through operational screens.
  • Page 18: Installation Instructions

    4. Once connected, power cycle the system and 006-700R ensure display is working properly. NOTE: CANNOT OPERATE APPLICATOR SYSTEM WITH HARVEST TEC DISPLAY AND BALER ISO INTEGRATION or TABLET/ iPAD AT THE SAME TIME. Optional Android Display Kit (030-1670DK) Description...
  • Page 19: Optional Ipad Mini Display Kit

    Optional iPad Display Kit (030-4670DK) Description Part # iPad Mini 4 (Refurbished) 006-4670IP Complete iPad Mini Kit 030-4670DK Suction Cup Mount 001-2012SCM (Includes 1-5 and Comm. Cable) Ram Mount 001-2012H Spring Load Cradle 001-2012SLC Mounting Kit Only 030-2014MK (Includes all parts except iPad Mini 4) iPad Mini 4 Case 001-2012C4 Lightning Comm.
  • Page 20: Optional Isc Display Adapter

    The 700 Series Applicator has the option to tie into compatible dedicated ISO monitors by utilizing the diagnostic port. When connected, the Harvest Tec System will populate as its own object pool within the ISO display. When this object pool is selected, the ISO monitor will then function as a dedicated monitor for the Harvest Tec System.
  • Page 21: Optional Crop Eye Forage Indicators

    Drill 2x 5/16” holes aligned with the center of the slots. Secure the brackets to the shield using the supplied hardware, assembly loosely until sensors have been aligned. Upon completion of alignment, tighten the hardware. Route sensor wiring downward and away from moving parts. Harvest Tec 474C Parts Breakdown Ref# Description...
  • Page 22: Wire Diagram

    A. The power harness must be connected to the battery! CONTACT HARVEST TEC BEFORE MODIFICATIONS. *The unit will draw more amps than convenience outlets can handle. Any modifications of the power harness will void systems warranty* B.
  • Page 23: Pin Outs

    Pin Outs Integrated Control Module (ICM) on Tractor Harness 006-765IC (Deutsch Plug Number: DTM06-12SA) Pin 1 +12V from ECU Pin 2 Purple Signal Wire Pin 3 Red/White +12V CAN X Pin 4 Black/White Ground CAN X Pin 5 Orange CAN X Hi Pin 6 Blue CAN X Lo...
  • Page 24 Pin Outs (continued) Power / Communication Baler Harness 006-765B at Baler Hitch IPM (Deutsch Plug Number: HDP26-24-18SN) Pin 1 Not Used ---- Pin 2 Yellow ISO CAN Hi Pin 3 Green ISO CAN Lo Pin 4 +12V Power to ECU Pin 5 Black Ground to ECU...
  • Page 25 Pin Outs (continued) CAN / IDM on Baler Harness 006-765B (Deutsch Plug Number: DT06-4S) Pin 1 +12V to Solenoid 2 Pin 2 Yellow ISO CAN Hi Pin 3 Green ISO CAN Lo Pin 4 Black Ground to Solenoid 2 End of Bale Sensor Plug on Baler Harness 006-765B (Deutsch Plug Number: DT06-3S) Pin 1 Orange/White...
  • Page 26: Warranty Statement

    Harvest Tec, LLC. within 30 days of the failure. If it is determined that a non-Harvest Tec branded hay preservative has been used inside the Harvest Tec applicator system where the failure occurred, then Harvest Tec reserves the right to deny the warranty request at their discretion.
