2 Board Information

2.1 Physical Specifications

The ADM-PCIE-9V8 complies with PCI Express CEM revision 3.0.
Page 2
Description
PCB Dy
Total Dx
PCB Dz
Table 1 : Mechanical Dimensions (PCB only)
Description
Total Dy
Total Dx
Total Dz
Weight
Table 2 : Mechanical Dimensions (Fully Assembled)
Figure 2 : ADM-PCIE-9V8 Fully Assembled
ADM-PCIE-9V8 User Manual
Measure
100.15 mm
239.0 mm
1.6 mm
Measure
126.35 mm
252.2 mm
19.7 mm
600 grams (without
QSFP-DD modules)
Board Information
