Alpha Data ADM-PCIE-9V8 User Manual page 33

ADM-PCIE-9V8 User Manual
Pin
Number
AY33 FIREFLY_3_INT_1V8_L
BE31 FIREFLY_3_MODPRS_L
AV33 FIREFLY_3_RST_1V8_L
AP3
AP4
AN1
AN2
AM3
AM4
AL1
AL2
AU32
AW34
AT8
AT9
AR6
AR7
AP8
AP9
AN6
AN7
AE10 FIREFLY_CLK_0_PIN_N
AE11 FIREFLY_CLK_0_PIN_P
AN10 FIREFLY_CLK_1_PIN_N
AN11 FIREFLY_CLK_1_PIN_P
BC11
BF17
BD13
BE12
BD11
BE11
AU20
AU19
AR18
Complete Pinout Table
ad-ug-1467_v1_0.pdf
Signal Name
FIREFLY_3_RX0_N
FIREFLY_3_RX0_P
FIREFLY_3_RX1_N
FIREFLY_3_RX1_P
FIREFLY_3_RX2_N
FIREFLY_3_RX2_P
FIREFLY_3_RX3_N
FIREFLY_3_RX3_P
FIREFLY_3_SCL_1V8
FIREFLY_3_SDA_1V8
FIREFLY_3_TX0_N
FIREFLY_3_TX0_P
FIREFLY_3_TX1_N
FIREFLY_3_TX1_P
FIREFLY_3_TX2_N
FIREFLY_3_TX2_P
FIREFLY_3_TX3_N
FIREFLY_3_TX3_P
FPGA_FLASH_CE0_L
FPGA_FLASH_CE1_L
FPGA_FLASH_DQ0
FPGA_FLASH_DQ1
FPGA_FLASH_DQ2
FPGA_FLASH_DQ3
FPGA_FLASH_DQ4
FPGA_FLASH_DQ5
FPGA_FLASH_DQ6
Table 10 : Complete Pinout Table (continued on next page)
Pin Name
IO_L19N_T3L_N1_DBC_AD9N_68
IO_L4N_T0U_N7_DBC_AD7N_68
IO_L20P_T3L_N2_AD1P_68
MGTFRXN0_226
MGTFRXP0_226
MGTFRXN1_226
MGTFRXP1_226
MGTFRXN2_226
MGTFRXP2_226
MGTFRXN3_226
MGTFRXP3_226
IO_L21P_T3L_N4_AD8P_68
IO_L20N_T3L_N3_AD1N_68
MGTFTXN0_226
MGTFTXP0_226
MGTFTXN1_226
MGTFTXP1_226
MGTFTXN2_226
MGTFTXP2_226
MGTFTXN3_226
MGTFTXP3_226
MGTREFCLK0N_228
MGTREFCLK0P_228
MGTREFCLK0N_226
MGTREFCLK0P_226
RDWR_FCS_B_0
IO_L2N_T0L_N3_FWE_FCS2_B_65
D00_MOSI_0
D01_DIN_0
D02_0
D03_0
IO_L22P_T3U_N6_DBC_AD0P­
_D04_65
IO_L22N_T3U_N7_DBC_AD0N­
_D05_65
IO_L21P_T3L_N4_AD8P_D06_65
Bank Voltage
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT
1.8 (LVCMOS18)
1.8 (LVCMOS18)
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT
MGT REFCLK
MGT REFCLK
MGT REFCLK
MGT REFCLK
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
1.8 (LVCMOS18)
Page 29
