3.6.1 System Monitor Status LEDs
LEDs D7 (Red) and D9 (Green) indicate the card health status.
Page 16
LEDs
Green
Green + Red
Flashing Green + Flashing Red
(together)
Flashing Green + Flashing Red
(alternating)
Flashing Green + Red
Red
Flashing Red
Table 8 : Status LED Definitions
Status
Running and no alarms
Standby (Powered off)
Attention - critical alarm active
Service Mode
Attention - alarm active
Missing application firmware or
invalid firmware
FPGA configuration cleared to
protect board
