ADM-PCIE-9V8 User Manual

3.6 System Monitor

The ADM-PCIE-9V8 has the ability to monitor its own temperature and the voltages and currents of certain power
supply rails, in order to provide an indication of board health. The monitoring is implemented using an Atmel AVR
microcontroller.
If the core FPGA temperature exceeds 105 degrees Celsius, the FPGA will be cleared to prevent damage to the
card.
The microcontroller monitors power supply rail voltages & currents and temperatures at certain points on the
board. This information can be read out via USB using the avr2util utility, and also via PCIe if RD-9V8 is
purchased.
Monitors
ETC
EC
12V_AUX
12V_AUX_I
12V_EDGE
12V_EDGE_I
3V3_EDGE
3V3_AUX
3V3_DIG
2V5_CLK
1V8_DIG
1V8_MGT_AUX
1V2_AVTT
0V9_AVCC
VCC_INT
GND
uC_Temp
Board0_Temp
Board1_Temp
FPGA_Temp
Functional Description
ad-ug-1467_v1_0.pdf
Identifier
Purpose/Description
ETC
Elapsed time counter (seconds)
EC
Event counter (power cycles)
ADC00
12v board input supply from 6-pin ATX Cable
ADC01
12V input current from 6-pin ATX Cable in amps
ADC02
12V board input supply from PCIe Edge
ADC03
12V board input current from PCIe Edge in amps
ADC04
3.3V board input supply from PCIe edge (unused)
ADC05
3.3V auxilary board input supply from PCIE edge
ADC06
3.3V generated onboard for QSFP optics
ADC07
2.5V generated onboard for clock circuitry
ADC08
1.8V generated onboard fpr FPGA IO voltage (VCCO)
ADC09
1.8V generated onboard for transceiver power (AVCC_AUX)
ADC10
1.2V generated onboard for transceiver Power (AVTT)
ADC11
0.9V generated onboard for transceiver Power (AVCC)
0.85-0.90V generated onboard for VccINT + VccBRAM +
ADC12
VccINT_IO
ADC13
0V electrical ground
TMP00
uC on-die temperature
TMP01
Board temperature near front panel (U3)
TMP02
Board temperature near back edge (U23)
TMP03
FPGA on-die temperature
Table 7 : Voltage, Current, and Temperature Monitors
Page 15
