Technical Data

This Intatherm thermostatic mixer tap is suitable for installations on all types of plumbing
system, including gravity supplies, fully pumped, modulating combination boiler, unvented
water heater and unbalanced supplies i.e. Cold Mains
suitable for non-modulating combination boilers.
Max Inlet Pressure (Static)
Max Inlet Pressure (Dynamic)
Max Inlet Temperature
Min Inlet Temperature
Pre Set Factory Temp Setting
Min Operating Pressure (Dynamic) 0.2 bar
Temperature Stability
Dimensions
© Intatec Ltd 2013
12 bar
5 bar
85˚C
10˚C
38˚C
± 2˚C
IT1006CP - 190
IT1005CP - 140
Ø49.5
3
Tank Fed Hot. They are not
Max Unbalanced Pressure Ratio
with flow regulator
Max Unbalanced Pressure Ratio
without flow regulator
Min Temp Differential to
ensure fail-safe between hot
and cold supplies
15:1
5:1
10˚C
