i-sport Shower Panel
SP9206CP & SP9207CP
Installation and Maintenance Instructions
Intatec Ltd
Airfield Industrial Estate
Hixon
Staffordshire
ST18 0PF
In this procedure document we have endeavoured to make the
information as accurate as possible
Tel: 01889 272 180
We cannot accept any responsibility should it be found that in
Fax: 01889 272 181
any respect the information is inaccurate or incomplete or
email: sales@intatec co uk
becomes so as a result of further developments or otherwise
web: www intatec co uk
© Intatec Ltd. 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Inta i-sport SP9206CP
Summary of Contents for Inta i-sport SP9206CP
- Page 1 i-sport Shower Panel SP9206CP & SP9207CP Installation and Maintenance Instructions Intatec Ltd Airfield Industrial Estate Hixon Staffordshire ST18 0PF In this procedure document we have endeavoured to make the information as accurate as possible Tel: 01889 272 180 We cannot accept any responsibility should it be found that in Fax: 01889 272 181 any respect the information is inaccurate or incomplete or email: sales@intatec co uk...
- Page 2 These instructions cover the installation, operation and maintenance. Please read the enclosed instructions before commencing the installation of this product, please note; We recommend that the installation of any Inta product is carried out by an approved installer The installation must be carried out strictly in accordance with the Water Supply (Water Fitting) Regulations 1999 and any local authority regulations.
- Page 3 Before commencing remove all components from packaging and check each component with the contents list. Ensure all parts are present, before discarding any packaging. If any parts are missing, do not attempt to install your Inta compact shower panel until the missing parts have been obtained. © Intatec Ltd 2014...
-
Page 4: Technical Data
Technical Data This Inta i-sport compact shower panel is suitable for using recirculating hot water systems and from a calorifier or hot water storage cylinder. Water pressure range: 1 to 6 bar Recommended water pressure range: 2 to 4 bar Water temperature range: 5 to 65˚C... -
Page 5: Installation
Installation The whole system should be thoroughly flushed, prior to the connection of the water supply to the shower or thermostatic mixing valve, to remove any debris that may be in the supply pipework. The i-sport compact panel shower should be positioned at a convenient height for most users as illustrated below. -
Page 6: External Supply
External Supply • The shower panel is supplied for an external water supply from above. • Remove the shower head cover (2) from the shower panel. • Using the 6 fixing holes in the shower panel as a template mark their positions on the wall or use to drill pilot holes. - Page 7 Concealed Supply Installer to apply suitable Loctite thread sealant - 2 drops © Intatec Ltd 2014...
- Page 8 Concealed Supply Cont The shower panel can be supplied by a concealed supply, through a wall or panel. • Fit the blanking cap (10) to the top external supply connection. • The concealed supply must terminate with a G½ parallel female thread. •...
-
Page 9: Completing The Installation
Completing the Installation • Fit the shower head cover (2) to the panel and secure it in position with the self-taping screw (4). • Remove the screws caps (9) from the bottom of the panel and fit them as shown. ©... -
Page 10: Operating The Shower
Operating the Shower • Push the operating button (A), a small quantity of water will be discharged through an outlet in the lower part of the panel (C). THIS WATER DISCHARGE IS NECESSARY FOR THE CONTINUING OPERATION OF THE SELF CLOSING VALVE (B), FOR THIS REASON THE OUTLET HOLE MUST BE KEPT UNRESTRICTED •... - Page 11 Dimensions G½B © Intatec Ltd 2014...
- Page 12 Aftercare Inta i-sport compact shower panel has a high quality finish and should be treated with care. An occasional wipe with a mild washing-up liquid on a soft damp cloth followed by a thorough rinsing is all that is required.
