IntaKlean
Installation & Servicing Instructions
IKMF22 and IKMF28
Intatec Ltd
Airfield Industrial Estate
Hixon
Staffordshire
ST18 0PF
In this procedure document we have endeavoured to make the
information as accurate as possible
Tel: 01889 272 180
We cannot accept any responsibility should it be found that in
Fax: 01889 272 181
any respect the information is inaccurate or incomplete or
email: sales@intatec co uk
becomes so as a result of further developments or otherwise
web: www intatec co uk
© Intatec Ltd. 2012
Advertisement
Related Manuals for Inta IntaKlean Series
Summary of Contents for Inta IntaKlean Series
- Page 1 IntaKlean Installation & Servicing Instructions IKMF22 and IKMF28 Intatec Ltd Airfield Industrial Estate Hixon Staffordshire ST18 0PF In this procedure document we have endeavoured to make the information as accurate as possible Tel: 01889 272 180 We cannot accept any responsibility should it be found that in Fax: 01889 272 181 any respect the information is inaccurate or incomplete or email: sales@intatec co uk...
-
Page 2: Installation
INSTALLATION The IntaKlean triple action filter is suitable for installation on any central heating system and can be fitted anywhere in any orientation. For best performance and filter protection however, we recommend that the IntaKlean is installed on the return leg of the circuit, between the last radiator and the boiler to gain the maximum advantage of the IntaKlean’s vortex technology. - Page 3 INSTALLATION Ensure that the system is suitably drained down and all system pressure has been released. On open vented systems, make sure that the feed and expansion tank is either isolated or “tied up”. When siting the IntaKlean ensure that the collection vessel is positioned to allow access and removal of the bottom cover, withdrawl of the magnetic element and venting air.
- Page 4 INSTALLATION Slip the collection vessel between the isolation valves making sure that the sealing washers are fitted and that the flow direction arrow on the body is pointing in the same direction as the flow. The air vent must be at the top of the collection vessel and the cover at the bottom. Hand tighten the valves to the collection vessel before fully tightening.
-
Page 5: Cleaning And Servicing
CLEANING AND SERVICING Prior to cleaning the IntaKlean, ensure that the working environment is safe. Inta recommend that the boiler is switched off and that the system is allowed to cool to ambient temperature before commencing any maintenance works. Isolate the IntaKlean by closing the two ball valves and opening the air vent. - Page 6 CLEANING AND SERVICING Magnetic Core Plastic Sheath ‘O’ring Metal Screen Cover Container Check the ‘O’ ring seal for signs of damage, replace if damaged. Re-assemble in the reverse order, check joints for signs of leakage before recommissioning following the procedure in the COMMISSIONING section. ©...
- Page 7 ADDING WATER TREATMENT To add water treatment chemicals via the IntaKlean, first ensure the system is appropriately isolated then close the upper ball valve leaving the lower valve open. Drain a suitable volume of water from a drain point at the lowest part of the central heating system.
- Page 8 NOTES Please Leave this Manual for the User Intatec Ltd Airfield Industrial Estate Hixon Staffordshire ST18 0PF Tel: 01889 272 180 Fax: 01889 272 181 email: sales@intatec co uk web: www intatec co uk © Intatec Ltd 2012 17-10-12...
