Intatherm Safe Touch Basin Tap
IT1007CP
Installation and Maintenance Instructions
Intatec Ltd
Airfield Industrial Estate
Hixon
Staffordshire
ST18 0PF
In this procedure document we have endeavoured to make the
information as accurate as possible.
Tel: 01889 272 180
We cannot accept any responsibility should it be found that in
Fax: 01889 272 181
any respect the information is inaccurate or incomplete or
email: sales@intatec.co.uk
becomes so as a result of further developments or otherwise.
web: www.intatec.co.uk
© Intatec Ltd 2022
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Inta IT1007CP
Summary of Contents for Inta IT1007CP
- Page 1 Intatherm Safe Touch Basin Tap IT1007CP Installation and Maintenance Instructions Intatec Ltd Airfield Industrial Estate Hixon Staffordshire ST18 0PF In this procedure document we have endeavoured to make the information as accurate as possible. Tel: 01889 272 180 We cannot accept any responsibility should it be found that in...
- Page 2 Before commencing remove all components from packaging and check each component with the contents list. Ensure all parts are present, before discarding any packaging. If any parts are missing, do not attempt to install your Inta tap until the missing parts have been obtained. © Intatec Ltd 2022...
- Page 3 Components Item Qty Component Body Indice Retaining screw Handle Thermostatic cartridge Nozzle Sealing ring Horse shoe plate Threaded rod Retaining nut 350mm copper tail integral with body Connector with check valve and filter © Intatec Ltd 2022...
-
Page 4: Technical Data
Technical Data This Intatherm thermostatic mixer tap is suitable for installations on all types of plumbing system, including gravity supplies, fully pumped, modulating combination boiler, unvented water heater and unbalanced supplies i.e. Cold Mains & Tank Fed Hot. They are not suitable for non-modulating combination boilers. -
Page 5: Installation
The Intatherm thermostatic basin tap is designed for installing on one hole basins. The IT1007CP tap is supplied with two 350mm long copper tails ready to be fitted to the tap. Each tail is supplied ready to connect to the compression connector with integral check valve and filter (12). - Page 6 Calibration The Intatherm safe touch mixer tap has a factory set outlet temperature of 43˚C via the security setting. This is based on a balanced supply pressure and a stable hot water inlet temperature of 65˚C. However, the calibration point MUST be checked and re-set as necessary to suit site conditions.
-
Page 7: Cartridge Replacement
The nozzle should be cleaned periodically to remove any build up of debris or deposits which may affect the performance of the tap. Inta taps have a high quality finish and should be treated with care. An occasional wipe with a mild washing-up liquid on a soft damp cloth followed by a thorough rinsing is all that is required. -
Page 8: Technical Specification
Intatherm Thermostatic Basin Tap Introduction The Intatherm safe touch thermostatic basin tap has been specifically designed and manufactured to meet the requirements of BS 7942:2011 and NHS D08. Technical Specification Outlet Temperature Adjustment Range 30˚C to 50˚C Temperature Stability ±2˚C Maximum Hot Inlet Temperature 85˚C DO8 Working Pressure Range... -
Page 9: Temperature Setting
Refit the handle in the reverse order. Installation IMPORTANT - The following instructions must be read prior to the installation of any Inta basin tap. The installer should also be aware of their responsibility and duty of care to ensure that all aspects of the installation comply with all current regulations and legislation. - Page 10 Installation 3 The supply system to which the Intatherm thermostatic basin tap is to be installed into must be thoroughly flushed and cleaned to remove any debris, which may have accumulated during the installation. Failure to remove any debris will affect the performance and the manufacturer’s warranty of the product.
- Page 11 Commissioning 2 Commissioning the temperatures must be carried out using a suitably calibrated thermometer preferably a digital thermometer. 3 In the absence of other temperatures being specified, we recommend the outlet temperature quoted in Table 1 are used. Table 1 Application Recommended Set Mixed Water Temp.
-
Page 12: Maintenance
Maintenance To ensure the Intatherm thermostatic basin tap maintains a high level of protection, we advise the following in service testing is conducted (the same equipment used to commission the basin tap initially must be used in the following tasks). 1 After a period of between 6 and 8 weeks from commissioning carry out the following;... - Page 13 8 In all areas periodic maintenance of the valve and associated fittings i.e. strainers, check valves will ensure optimum performance levels are maintained. Spares A full range of spares are available for this product from Inta. PLEASE NOTE: Only genuine spares should be used. © Intatec Ltd 2022...
- Page 14 Notes: © Intatec Ltd 2022...
- Page 15 Notes: © Intatec Ltd 2022...
- Page 16 Please leave this Manual for the User To active your product warranty please visit www.intatec.co.uk and click on Product Registration Intatec Ltd Airfield Industrial Estate Hixon Staffordshire ST18 0PF Tel: 01889 272 180 Fax: 01889 272 181 email: sales@intatec.co.uk web: www.intatec.co.uk E &...
