Front Panel - RGBlink mini-edge Quick Start Manual

Volume Control
Function Settings
● 5.5" HD Screen
● SHORTCUTS/Number Button
● MENU/EXIT/LOCK Button
● Menu Browsing/Confirm Button (ENTER)
● RECORD Button
● ON AIR Button
Camera Control
● FUCUS Button with Indicator
● Toggle
● 5-Direction Joystick
Volume Control
● Volume Control Knob
● AFV Button
● Mute Button
www.rgblink.com

Front Panel

Camera Control Function Settings
Layer Settings
Transition
● Transition Effect Selection Button (EFFECTS)
● Transition Duration Selection Button (DURATION)
● T-Bar
● CUT Button
● AUTO Button
Layer Settings
● Layout Selection Button (PICTURE-IN-PICTURE)
● Chroma Key
● Layer A/B Button
● Preset Loading Button (VIEWS)
● PROGRAM Source Row
● PROGRAM Layer Button
● PROGRAM FTB Button
● PREVIEW Source Row
● PREVIEW Layer Button
● PREVIEW Clear Button
Transition
3
