Controlling Ptz Cameras - RGBlink mini-edge Quick Start Manual

Selecting Layout
Same as operations in
required in LAYOUT interface.
Controlling PTZ
mini-edge supports simultaneous control of up to
four cameras.
Warning:
Check if port number of camera is set to 1259. If not,
enter correct port number of the controlled camera.
www.rgblink.com
Adding Layer A, choose layout

Controlling PTZ Cameras

Adjusting Position
Use the joystick to quickly adjust the horizontal
position and vertical position.
Setting IP Address Manually
The IP address of mini-edge and camera controlled
should be in the same LAN.
Please follow the steps outlined as follows to set IP
address.
1. Rotate ENTER knob to move the cursor to"IP";
2. Press ENTER knob and use number buttons along
the Shortcut Row to enter IP address；
3.
Rotate ENTER knob to move the cursor to
"Enter", then press the knob again to save.
15
