Front Panel - RGBlink mini-pro v3 Quick Start Manual

No. Item
❶ Toggle
❷ S Button
❸ Touch Screen
❹ M Button
5-Direction
❺
Joystick
①②③④
❻
❼ T-Bar
www.rgblink.com

Front Panel

❻
Description
Preset Menu: Adjust Program volume.
●
:
● PIP Mode Proportionally adjust size of sub-picture.
:
● PTZ Control Zoom in and zoom out.
Adjust IP values.
● IP Setting:
Press shortcut button to enter quick operation interface, which includes 8
Presets to load, Audio, Record on/off, Stream on/off.
● For menu operation and
● PTZ Control：Monitor the screen of the currently controlled camera, and
save the currently set screen by tapping it, and a call button can be formed.
● Single Click
○ 4-window Monitoring Interface: Press to enter Menu Interface.
○ Menu Interface: Press to enter 4-window Monitoring Interface.
○ Others: Press to exit.
● Long Press
○ 4-window Monitoring Interface: Press to lock control panel.
○ Others: Press to 4-window Monitoring Interface.
● Move Up/Down/Left/Right
○ Menu Interface: Move the cursor for item selection.
○ PTZ Control: Set pan, tilt and zoom for PTZ camera.
○ Layer Adjustment: Position adjustment for sub-layer.
● Short Press
○ To enter the next higher level of menu.
○ PTZ Control: Control left, right, up and down movement of camera.
○ Others: To enter PTZ Control Interface.
● Button Unlit: no input signal.
● Button Lit White：unselected input signal.
● Button Blinked Green: Preview out.
● Button Lit Red: Program out.
Preview and Program views can be transitioned by pushing T-Bar.
❻
❼
4 inputs
monitoring.
