Sending RTP Stream

To configure a multicast paging key via phone interface
Press Menu→Feature →line or Line Key→Line Key1（e.g.）
1.
2. Press and
3. Enter the multicast IP address and port number (e.g., 224.5.6.20:2000) in the Value
field.
4. The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
5. Press or Save soft key to save the configuration
To configure a multicast paging key via web interface
1.
2.
3.
224.5.6.20:2000) in the Value field.
The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
4.
Sending RTP Stream：
Press the multicast paging key when the phone is idle.
The phone sends RTP to a preconfigured multicast address (IP: Port). Any phone in the
local network then listens to the RTP on the preconfigured multicast address (IP:Port). For
both sending and receiving of the multicast RTP, there is no SIP signaling involved.
The multicast paging key LED illuminates solid green.

Receiving RTP Stream

You can configure the phone to receive a Real Time Transport Protocol (RTP) stream from
or switch key to select the multicast paging in the type field.
Function keys->line key：
Select the desired Key and select multicast paging in the Type.
Enter the multicast
Click the
Function Key Features Settings
IP address and port
button to save the configuration.
number (e.g.,
