Multicast Paging

You can use multicast paging to quickly and easily forward out time sensitive
announcements to people within the multicast group. You can configure a multicast paging
key or a paging list key on the phone, which allows you to send a Real Time Transport
Protocol (RTP) stream to the pre-configured multicast address/addresses without
involving SIP signaling. You can configure the phone to receive an RTP stream from
pre-configured multicast listening address/addresses without involving SIP signaling. You
can specify up to 10 multicast listening addresses.

Sending RTP Stream

To configure a multicast paging key via Phone interface
Press Menu →Feature →Line Key →Line Key2（e.g.）
1.
2. Press and
3. Enter the multicast IP address and port number (e.g., 224.5.6.20:2000) in the Value
field.
4. The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
5. Press or Save soft key to save the configuration
To configure a multicast paging key via Web interface
1. Function Keys->Line key：
2. Select the desired Key and select Multicast Paging in the Type.
3. Enter the multicast IP address and port number (e.g., 224.5.6.20:2000) in the Value
field.
The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
4. Click the
Sending RTP Stream:
Press the multicast paging key when the phone is idle.
The phone sends RTP to a preconfigured multicast address (IP: Port). Any phone in the
or switch key to select the Multicast Paging in the Type field.
button to save the configuration.
