the pre-configured multicast address(es) without involving SIP signaling. You can specify
up to 10 multicast addresses that the phone listens to on the network.
How the phone handles incoming multicast paging calls depends on Paging Barge and
Paging Priority Active parameters configured via web user interface.
Paging Barge
The paging barge parameter defines the priority of the voice call in progress. If the priority
of an incoming multicast paging call is lower than that of the active call, it will be ignored
automatically. If Disabled is selected from the pull-down list of Paging Barge, the voice call
in progress will take precedence over all incoming multicast paging calls.
Valid values in the Paging Barge field:
 1 to 10: Define the priority of the active call, 1 with the highest priority, 10 with the lowest.
 Disabled: The voice call in progress will take precedence over all incoming paging calls.
Paging Priority Active
The paging priority active parameter decides how the phone handles incoming multicast
paging calls when there is already a multicast paging call on th e phone. If enabled, the
phone will ignore incoming multicast paging calls with lower priorities, otherwise, the
phone will answer incoming multicast paging calls automatically and place the previous
multicast paging call on hold. If disabled, the phone will automatically ignore all incoming
multicast paging calls.
Multicast Codec:
You can only configure the codec by web interface.
To configure multicast codec key via web interface
1.
2.
3.
To configure multicast listening addresses via web interface:
1.
Click Directory->Multicast paging。
2.
Select the desired value from the pull-down list of Paging Barge.
3.
Select the desired value from the pull-down list of Paging Priority Active.
4.
Enter the multicast IP address(es) and port number (e.g., 224.5.6.20:2000) which the
phone listens to for incoming RTP multicast in the Listening Address field.
5.
Enter the label in the Label field.
Click Directory ->Multicast Paging:
Select the desired codec from the pull-down list of Multicast Codec
Click the
Function Key Features Settings
button to save the configuration.
167
