RANGE HOOD CARE

Cleaning
WARNING
To reduce the risk of electrical shock, DO NOT
clean the hood while it's operating.
Never put your hands into the area housing the
fan when the fan is operating.
Cleaning the Exterior Surfaces
IMPORTANT
To avoid damage to the exterior surfaces:
DO NOT use corrosive or abrasive detergent.
DO NOT use steel wool, scoring pad or steel
brushes. Use a paper towel or soft cloth or
nonabrasive sponge instead.
DO NOT use salt solutions, disinfectants,
bleaches or cleaning compound that contains
harmful chemicals.
Cleaning Method:
Noncorrosive or nonabrasive liquid detergent
soap or all-purpose liquid cleanser.
Wipe the surfaces with a damp paper towel or
soft cloth or nonabrasive sponge.
Rinse with clean water.
Wip dry with dry towel or cloth.
Note
The nonabrasive stainless steel polisher can
be applied when done cleaning to retain the
stainless luster and grain.
Always follow the instrunction of the polisher.
Cleaning the Stainless Steel Baffle Filters
Pull the spring release handle and remove the
filter by pulling it down.
Wash the filter in the top rack of the
dishwasher or with warm soapy solution
manually.
Let the filters dry thoroughly.
Make sure the spring release handle is toward
the front, align and insert the filter.
Pull the spring release handle and push the
filter into position.
10
Release the handle.
Repeat the steps for the remaining filters.
Replacing the Filters:
Replace the baffle filters immediately should
they become worn out due to aging or
prolonged usage.

Replacing the LED Lamps

WARNING
Electrical Shock Hazard
Disconnect power before servicing
Wear gloves to protect against sharp edges
This range hood uses 12V, 3W LED.
Unplug the range hood, or turn off the breaker.
Remove the Baffle Filters and the Screws on
both sides.
Flip the stainless steel Panel open on the
longest side, locate and disconnect the Wires
for the LED Lamps and the Control Panel.
LED Lamp
Control Panel
Disconnect
the Wires
Remove the old lamps and install new lamps.
Connect the wires to the new Lamp.
Align and put the new Lamp back into position.
Press the edge of the new Lamp until it
touches the bottom of the Hood Unit.
Put the Baffle Filter back into place.
Plug in the range hood, or turn on the breaker.
Check if the new Lamp is working properly.
