INSTALLATION
Installing the Blower Unit
• Install the mounting brackets to the
edges of the Blower Unit with the screws
provided.
• Install the Blower Unit onto the lumbers in
the attic.
• Route the Speed Control Cord and Duct
to the Blower Unit. Use duct elbows to
make turns only when it's needed. Cut
and remove the excess length when done
routing.
• Connect the duct to the Blower Unit's vent
in adapter routed from the Hood Unit.
• Connect the duct from the Blower Unit's
vent out adapter to the roof or wall vent
out.
• Connect the Duct from the roof to the vent
opening next to the Black Connection Box.
• Use foil tape or duct tape to seal all
connections.
• Connect the Speed Control Cord from
the Hood Unit to the Connection Box on
the Blower Unit. See Electrical Connection
section for how to properly connect the
wires.
CAUTION
For safety purpose, please connect a separate
Gound Wire to the Blower Unit Chassis screw.
(Note, don't connect the Ground wire to
Blower Unit's Green Speed Wire!!!)
Important
If you have an Awoco Exterior Blower Unit, or
•
any Blower Unit from other Brands:
• DO NOT CONNECT the wires as shown
in the Wiring Diagram. Any damage from
false wiring is not covered by the warranty.
• Refer to your Blower Unit's USER
MANUAL for how to properly connect the
wires.

Electrical Connection

• Connecting the Blower Unit to the Hood Unit
is as simple as "Match Colors and Connect":
• Simply pick the wires with the same
8
color from both ends and secure them
with a wire nut connector. (Refer to the
Wiring Diagram in the Test Run section for
how to connect the wires properly.)
• This range hood comes with a power cord
with a 3-prong plug. Connect the power cord
to a designated grounded standard 110V
outlet.
Warning
Before Plugging the Power Cord to the Outlet:
• Make sure all wires are
connected properly
between the Hood
Unit and the Blower
Unit.
• Insolate any spare wires with electrical tape
to prevent them from touching each other
which will result in a short circuit.
Electrical Shock Hazard
Disconnect power before servicing
• In case of a direct connection to the house
wiring is preferred, do the following:
• Disconnect the power.
• Cut off the plug from the power cord.
• Connect the wires from the power cord
to the wires from the house wiring using
UL listed wire connectors.
• Store the excess wires in the wiring box.
• Reconnect the power.
Installing the Baffle Filters
• Peel off the protective film from the baffle
filters if there's any:
• Soak the Baffle Filters into hot waters or
use heated air from a hair dryer to soften
the films.
• Peel off the films from the corner.
• Align the baffle filters with the Hood Unit and
install them from left to right.

Completing the Installation

Turn power ON in the control panel. Check all lights
and fan operations.
