Mychef COMPACT MASTER Product Manual page 45

Block Function
TO Device selection box
b On/Off button
c Start/Stop button
d Door status indicator
AND Equipment status indicator
F Wi-Fi indicator
g Phase 1 button (convection)
h Phase 2 button (mixed)
Yo Phase 3 button (steam)
J. Phase activation checkbox
Oven target temperature
K
input/indicator (Set Point)
Oven target humidity
l
input/indicator (Set Point)
Oven target cooking time
M
input/indicator (Set Point)
Real oven temperature
N
indicator (Real Point)
Real oven humidity indicator
EITHER
(Real Point)
Real oven cooking time
Q
indicator (Real Point)
mychefpro.com
Description
A list of all devices linked to the user account will appear in
this selection box.
Equipment on/off button.
Oven on/off and start/stop button.
Indicates whether the door is open (Open) or closed
(Close).
Indicates the different states of the equipment, see
section7.4.
Indicates the strength of the Wi-Fi signal using a
percentage.
Selecting this button redirects the front panel of the oven
to Phase 1 and displays its cooking parameters.
Selecting this button redirects the front panel of the oven
to Phase 2, activates it if it is disabled and displays its
cooking parameters. If it does not allow editing of the
parameters is disabled, it means that the phase is not
active. If the button text appears as if it is disabled, it means
that the phase is not active.
Selecting this button redirects the front panel of the oven
to phase 3, activates it if it is disabled and displays its
cooking parameters. If the button text appears as if it is
disabled, it means that the phase is not active.
Deselect if you want to deactivate a phase. Phase 1 is
always active.
Allows you to enter the desired temperature value in the
range [30,300] ºC for manual cooking or indicates the
target temperature value for a specific recipe.
Allows you to enter the desired humidity value in the range
[-100,100] % for manual cooking or indicates the target
humidity value for a specific recipe.
Allows you to enter the desired cooking time value in the
range [0-5940] minutes for manual cooking or indicates
the target cooking time value for a specific recipe.
Indicates the real-time temperature value of the oven
cooking chamber.
Indicates the real-time humidity value of the oven cooking
chamber.
Indicates the value of the cooking time that has passed
since cooking started.
COMPACT MASTER PRODUCT MANUAL - DT.MP.CM.2202.1
45
