Mychef COMPACT MASTER Product Manual page 20

Block Function
TO Convection button
Convection mode
b
indicator
c Mixed mode button
d Mixed mode indicator
AND steam button
F Steam mode indicator
g Display display
h Program button
Yo Adjustment button -
J. Adjustment button +
K Phase Button
l Humidity button
M Temperature button
Time or probe button
N
for COMPACT MASTER
EITHER Fan speed button
Quick memory button
p
block P1....P7
Q START/STOP button
CLEAN self-cleaning
R
button
The central screen is a very important part when interacting with the oven, since it indicates
the value of each cooking parameter.
mychefpro.com
Convection mode selection button.
Mark the chosen mode.
Mixed mode selection button.
Mark the chosen mode.
Steam mode selection button.
Mark the chosen mode.
Displays the selected parameter: humidity, temperature,
time or fan speed.
Allows you to record or recover a program.
Decreases the selected parameter: humidity,
temperature, time or fan speed.
Increases the selected parameter: humidity,
temperature, time or fan speed.
Phase selection button (Convection, mixed, steam).
Humidity selection button.
Temperature selection button.
Time selection button or activation of single-point /
sousvide probe in the case of Master.
Fan speed selection button.
With a long press, it records the current parameters in a
certain memory.
With a short press, it executes cooking in memory.
Oven on/off and start/stop button.
If the oven is on, but not cooking/washing, pressing
lightly will start the cooking/washing cycle.
If the oven is on and cooking/washing, pressing lightly
will cancel the cook/wash cycle.
Button for selecting the self-cleaning program on
COMPACT MASTERs.
Board6. Control panel description
COMPACT MASTER PRODUCT MANUAL - DT.MP.CM.2202.1
Description
