MTK982 User Manual

Group name

The second item on the Main menu is GROUP NAME; with this function is possible to assign or
change a name to a group of channel. This short name (8 character) is displayed at the right of the
group number in the main display view. First chose the group and then press the knob. You will be
able to edit any character of the group name rotating the knob. Push the knob to edit the next
character. Confirm or exit with the buttons.
NOTE: when the Group name is SYNC (see synchronization) it is not possible to change it.
Mode
The MODE menu allows to assign a Mode setting at the transmitter. Rotating the knob it is possible
to change current mode among the modes available.
TX on air at startup
This menu allows to decide if turn ON or turn OFF the RF power of the transmitter while the
MTK982 is powering on.
If set to No: while the MTK982 is powering on, the RF output remains mute. The Status Screen on
the display shows "TX OFF " and the set Group, Channel and frequency.
NOTE: When the RF power of the transmitter is OFF, all the led and the bars remain turned off.
Pushing the rotatory knob (at the right of the display) it is possible to activate the led and bars
(keeping the RF power OFF) and enter on the menu.
TX power
This menu allows to set the power of the transmitter. Rotating the knob it is possible to change
current TX power setting from 10 to 2000 mW.. In the same screen is showed the reflected power

Audio source

This menu allows to set several parameters of audio input
Parameters
Input
Max audio level
9
rev.03
In order to activate the RF output press the 3
at the bottom (see indication "ON" on the display).
If set to Yes: during the MTK982 power on, the
progress bar appears for 10 seconds.
During this interval (10 sec.) it is possible to switch off
the RF output. If no button is pushed, at the end of the
timer the RF output is enabled automatically.
Range setting Function
digital/analog To set the audio input
-6/0/6/12/18 dBu To change (increase or decrease) the analogue audio input for
and the SWR (Stationary Wave Ratio) sensing on
antenna outputs.
The set TX power and the measured SWR are always
showed at the bottom of the display.
rd
button
