rotate it to change the value of the parameter. The set value is showed on the bottom of the
windows (see points ❹ and ❺ on the above image).
Push the lower membrane button to go on the next windows.
The following table recaps the settable values on the 3 windows:
bass
mid
treble
NOTE: High Q factor means narrow bandwidth. Low Q factor means wide bandwidth.
Synchronization
The SYNC function is useful to tune a transmitter on the same frequency of the receiver via the IR
interface.
➢
Enable the IRDA on the receiver and place the IR windows of the receiver in front of the
IR interface of the transmitter as indicate in the below image.
➢
Press the SYNC button
both the displays
➢
Using the membrane buttons of the desired transmitter (TX1 or TX2) select:
•
TX->RX to set the receiver at the same frequency of the transmitter:
11
rev.03
Fr (frequency)
40/80/160 Hz
1.5/2.2/2.8kHz
5/7/10kHz
on the transmitter: the following message is showed on
G (gain)
-12÷12dB (1dB step)
TX->RX
Q (Q factor)
-
0.7/1.0/2.0
-
RX->TX
