9 Technical Specifications
Battery Model
Chemistry
Nominal Voltage
Voltage Range
Nominal Capacity
Nominal Energy
Unit Dimension
Unit Weight
Standard Charge/Discharge Current
Maximum Continuous
Charge/Discharge Current
Peak Current
Round-Trip Efficiency
Communication Protocol
Cycle Life
Calendar Life
Ambient Temperature
Certificates
Recommended Storage Temperature
E-BOX-48100R
LFP
51.2V
47.5V-57.6V
100Ah
5.12kWh
L440mm* W620mm * H117mm
（2.6U）
51kg
50A
50A
102A@15s
≥95%
RS232, RS485, CAN
≥6000cycles@0.5C/0.5C, 25℃
≥10years
0℃~ 35℃
UL1973, IEC62619 / UN38.3
20~30℃
Shanghai Pytes Energy Co., Ltd
