Personal protective equipment (PPE)

4.3 Determining the Installation Position

Installation Angle Requirement
The battery can be floor-mounted and wall-mounted. The installation angle requirement
is as follows:
⚫ Do not install the battery at forward tilted, back tilted, side tilted, horizontal, or
upside-down positions.
Installation Position Requirements
Install the battery on a solid brick-concrete structure or concrete wall or floor. If other
types of walls and floors are used, they must be made of fire-retardant materials and
meet the load-bearing requirements of the equipment.
Installation Space Requirements
⚫ During installation, ensure that there are no flammable or explosive materials
around the batteries. Reserve adequate space for heat dissipation and safety
isolation.
When the battery is mounted on a wall, do not place any objects under the
⚫
battery.
⚫ When install battery, no mattery it is cabinet or rack, please insure a minimum
300mm distance space for battery set. And the distance between battery and
inverter should be less than 10 meters.
range≥600VDC, AC Voltage
measurement range ≥ 600VAC)
Marker
Steel measuring tape
Level
Insulated gloves
Protective gloves
Dust mask
Safety boots
Safety goggles
Anti-static wrist ring
Shanghai Pytes Energy Co., Ltd
