  • Page 1 Installation and configuration manual With Deye Pytes Lithium Battery HV48100 With Deye Inverter...
  • Page 2 5 ) In case of fire, only dry powder fire extinguisher can be used, liquid fire extinguishers are prohibited ; 6 ) Please do not open, repair or disassemble the battery other than staffs from Pytes or authorized by Pytes. Pytes do not undertake an consequences or related responsibility caused by violation of safety operation or design, production and equipment safety standards;...
  • Page 3 Note :This part only includes the battery and inverter installation part. Please refer to other documents for the battery installation part.

  • Page 4: Table Of Contents

    CONTENTS BOM LIST ....................3 1. Communication Cable Connection ............8 2. Power Cable Connection ............... 9 3. Set The DIP Switch ................11 4. Start up the system ................12 5.Change the battery setting of the inverter ..........16 6.Check the battery soc ................17 7.System monitoring .................19...
  • Page 5 It is recommended to wear the following safety gears when dealing with the system.

  • Page 6: Bom List

    BOM LIST Before installation, you should prepare following items. Item Remarks Quantity ☐ Cable diameters: 4awg(≥25 mm) ☐ Only copper cables may be used. ☐ The DC cables must be sized for Power Cable 1pair (DC) the maximum battery voltage and the maximum battery current (see battery manufacturer documentation).

  • Page 7: Communication Cable Connection

    HOW TO INSATLL Communication cable Power cable connection connection Start up the system Set the DIP switch change the battery Check the battery soc setting of the inverter System monitoring CAUTION: If you want to get more inverter-related settings, please refer to the inverter user manual first.
  • Page 8 1. Communication Cable Connection Connect the end of the cable to the inverter communication port as shown in pic 1.1.1. Make sure use BMS1 port.

  • Page 9: Power Cable Connection

    Pic 1.1.1 Connect the other end of the cable to the BCUs CAN port as shown in pic 1.1.2. (Ensure the correct sequence of communication cable) Pic 1.1.2 2. Power Cable Connection Step.1 Insert the red cable into the positive DC connector ,Insert black cable into negative DC connector as shown in Pic 1.2.1.
  • Page 10 Pic 1.2.1 Step.2 At the other end of the cable, connect to the battery as shown Pic 1.2.2.（Ensure that the battery power switch is off）...

  • Page 11: Set The Dip Switch

    To Inverter To BMU Pic 1.2.2 3. Set The DIP Switch Before set the DIP switch,make sure the isolation switch is in the off state. Pic 1.3.1 Then set the DIP switch of BCUs as shown in Pic 1.3.2.

  • Page 12: Start Up The System

    Down，up, down, down, down, down Pic 1.3.2 4.Start up the system Before start up the inverters and batteries,make sure the wires are connected correctly.
  • Page 13 Step.1 Turn on the isolation switch.
  • Page 14 Pic 1.4.1 Step.2 Turn on the power switch .
  • Page 15 Pic 1.4.2 Step.3 Short press the red SW button, the RUN light on main control will flicker. Step.4 Press the inverter button, start the inverter.

  • Page 16: Change The Battery Setting Of The Inverter

    5.Change the battery setting of the inverter ※CAUTION:If you want more details about the batteries settings， please check the operating manual of inverters. Step1. Change the battery type to lithium in the Battery setting. Pic 5.1.1...
  • Page 17 Pic 5.1.2 Pic 5.1.3 Step2. Turn to the next page, use CAN communication,set the lithium mode to 00 .touch √ to confirm Pic 5.2.1...

  • Page 18: Check The Battery Soc

    6.Check the battery soc Step.1 Touch the battery icon of the inverter’s touch panel. Pic 6.1.1 Step.2 Click the Li-BMS in battery information page. Pic 6.1.2 The details of the battery will be shown on the parameter if the connection between battery and inverter is correct.

  • Page 19: System Monitoring

    Pic 6.1.3 7.System monitoring ※ CAUTION:If you want more details about system monitoring ， please check the operating manual of inverters. Download the app from the app store. Pic 7.1.2 Register a new account and create a new plant. -END-...
