- Page 1 Installation and configuration manual With Victron Energy Pytes Lithium Battery E-BOX series with Victron Energy Inverter/Charger...
-
Page 2: Table Of Contents
CONTENTS Bom List..................1 Power Cable Connection ..............6 Step1 ....................6 Step2 ....................6 Step3 ....................6 2. Communication Cable Connection ........3. Set the Dip Switch ..............4. Start up the System .............. 5. CAN-bus connection Setting ..........Step1 .................... -
Page 3: Bom List
BOM LIST Before installation, you should prepare following items. Item Remarks Quantity a): Conductor cross-section: 50 mm² to 95 mm² b): Cable diameters: 14 mm to 25 Depends on the number of Power Cable c): Only copper cables may be used. batteries and the (DC) d): The DC cables must be sized for... - Page 4 Definition CAN Port Pin for BMS is as follow. CAN port definition...
- Page 5 HOW TO INSATLL Communication Cable Power Cable Connection Connection Start up the System Set the DIP Switch Check out the battery CAN-bus Connection Parameters Setting Check out the Inverter System Monitoring Parameters CAUTION: If you want to get more inverter-related settings, please refer to the inverter user manual first.
-
Page 6: Power Cable Connection
1. Power Cable Connection Step.1 Open the front housing of the Victron Energy Inverter/Charger. Step.2 Connect the red and black cables to the inverter DC connector as shown in Pic 1.1 BATTERY+ BATTERY- Pic 1.1 Step.3 At the other end of the cable, connect to the battery as shown Pic 1.2 （Ensure that the battery power switch is off）... -
Page 7: Communication Cable Connection
2. Communication Cable Connection Insert inverter end of the CAN cable into the controller at VE.Can. Insert battery end of the CAN cable into the battery at CAN. (Ensure the correct sequence of wires inside the CAN cable). Insert VE.Bus cable two ends respectively into the inverter and the controller. -
Page 8: Set The Dip Switch
3. Set the DIP Switch Set the DIP switch as shown in 3.1 and graphic 1 Pic 3.1 graphic 1 4. Start up the System Start up the battery. Firstly, press the power button on, next press the SW red ring button as shown in pic 4.1. -
Page 9: Step1
Step1. Check the inverter indicator on and the controller screen lights on as shown in pic 5.1.1 and 5.1.2. Pic 5.1.1 Pic 5.1.2 Step2. Firstly, press Settings and down to the Services at the bottom line as shown in 5.2.1.and 5.2.2. Pic 5.2.1 Next, choose the CAN-bus line as shown in 5.2.3. -
Page 10: Step3
Pic 5.2.2 Pic 5.2.3 Pic 5.2.4 Step3. Check device connection as shown in pic 5.3.1, 5.3.2.and 5.3.3. -
Page 11: Check Out The Battery Parameters
Pic 5.3.3 6.Check out the Battery Parameters Firstly, check the battery basic parameters: SOC, Voltage and Current on the PYTES line as shown in pic 6.1. Next, go into PYTES, check more battery details, as shown in 6.2 and 6.3. -
Page 12: Check Out The Inverter Parameters
Voltage Current Pic 6.1 Power Pic 6.2 Pic 6.3 7.Check out the Inverter Parameters Step.1 Enter MultiPlus-Ⅱ48/5000/70-50 as shown in pic 7.1.1. -
Page 13: Step2
Check out the inverter Switch, AC output as shown in pic 7.1.2 and 7.1.3. Pic 7.1.1 Pic 7.1.2 Pic 7.1.3 Step.2 Check the device connection as shown in pic from 7.2.1.and 7.2.2. -
Page 14: System Monitoring
Pic 7.2.1 Pic7.2.2 8.System Monitoring ※CAUTION: If you want more details about system monitoring， please check the operating manual of inverters.
