RG-NIS3100 Series Switches Hardware Installation and Reference Guide
3.7

Bundling the Cables

Precautions
Bundle the power cords and other cables neatly.
When bundling fiber-optic cables, ensure that they have natural bends or large bend radius at the connectors.
Do not bundle fiber-optic cables and twisted pair cables too tightly, as this may press the cables and affect their
service life and transmission performance.
Bundling Steps
(1) Bundle the drooping part of the fiber-optic cables and twisted pair cables, and route them to both sides of the
chassis for convenience.
(2) On both sides of the chassis, fasten the fiber-optic cables and twisted pair cables to the cable management
bracket or trough.
(3) For the power cords, bundle them closely along the bottom of the chassis, in a straight line wherever
possible.
3.8

Verifying Installation

Danger
Turn off the power to avoid personal injury and damage to components caused by incorrect connection.

Verify that the grounding wire is properly connected.
Verify that the cables and power cords are properly connected.
Verify that the network cables with a length within 100 m (328.08 feet) are kept indoors. If not, check whether
the power supply and interfaces are protected against lightning strikes.
Verify that there is a minimum clearance of 100 mm (3.94 in.) around the device.
