RG-NIS3100 Series Switches Hardware Installation and Reference Guide
Product Introduction
Figure 1-11
Rear Panel for Wall Mounting
Note
1. DIN rail clamp
2. Screw holes for wall mounting
Note
To maintain the IP40 state of the device, fix the two screws back into their original positions in the DIN slot when
mounting the device on a wall.
15
