RG-NIS3100 Series Switches Hardware Installation and Reference Guide
Figure 1-5
Rear Panel for Wall Mounting
Note
1. DIN rail clamp
Note
To maintain the IP40 state of the device, fix the two screws back into their original positions in the DIN slot when
mounting the device on a wall.
5. Bottom Panel
Figure 1-6
Bottom Panel of NIS3100-8GT4SFP-HP
2. Screw holes for wall mounting
