RG-NIS3100 Series Switches Hardware Installation and Reference Guide
6. Bottom Panel
Figure 1-12 Bottom Panel of NIS3100-8GT2SFP-HP
Note 1. Nameplate
7. Cooling
The RG-NIS3100-8GT2SFP-HP adopts natural cooling to ensure that the device works properly under specified
environment. Maintain a minimum clearance of 100 mm (3.94 in.) around the device to ensure proper ventilation.
1.5 RG-NIS3100-4GT2SFP-HP
1.5.1 Technical Specifications
Model
CPU
BOOTROM
Flash Memory
SDRAM
Optical Module
SFP Port
Power Supply
RG-NIS3100-4GT2SFP-HP
Built-in MAC chip, single-core processor, 500 MHz clock speed
N/A
16 MB
DDR3 256 MB
See Appendix B. Copper cables are not supported.
The supported module types may update without prior notice. Please contact Ruijie
Networks for details.
The SFP port supports 1000BASE-X and 100BASE-FX.
DC input:
Rated voltage range: 12 V to 56 V
Rated current: 7 A
16
Product Introduction
