RG-NIS3100 Series Switches Hardware Installation and Reference Guide
get rusted.

In an environment with a low humidity, insulating strips may dry and shrink. Static electricity may occur easily
and endanger circuits on the device.

In an environment with a high temperature, the router is subject to more serious harm. Its performance may
degrade significantly and various hardware faults may occur.
Notice
●
There is no protective plate at the front or back of the rack.
●
The vertical height is 1.5 m above the floor.
●
The distance from the front panel of the device is 0.4 m.
2.2.6 Cleanness
Dust poses a severe threat to the running of the device. The indoor dust falling on the device may be absorbed by
the static electricity, causing bad contact of the metallic joint. Such electrostatic absorption may occur more easily
when the relative humidity is low. This affects the device lifecycle and causes communication faults. Table 2-2
lists the requirements for the dust content and granularity in the equipment room.
Table 2-2 Requirements for the Dust Content and Granularity in the Equipment Room
Apart from dust, the salt, acid and sulfide in
Dust
Diameter ≥ 0.5 μm
Diameter ≥ 5 μm
Apart from dust, the salt, acid, and sulfide in the air in the equipment room must also meet strict requirements.
This is because such poisonous substances may accelerate the corrosion of the metal and the aging of some
parts. The equipment room should be protected from the intrusion of harmful gases such as sulfur dioxide,
sulfured hydrogen, nitrogen dioxide, and chlorine. Table 2-3 lists the requirements.
Table 2-3 Requirements for Harmful Gases in the Equipment Room
Gas
SO
2
H S
2
NO
2
Cl
2
The average and maximum values are measured for a week. The switch cannot be placed in the
environment with the maximum density for over 30 minutes every day.
Unit Density
Particles/
≤ 3.5 x 10
3
m
Particles/
≤ 3 x 10
4
3
m
Average (mg/m3)
0.3
0.1
0.5
0.1
27
Preparation before Installation
6
Maximum (mg/m3)
1.0
0.5
1.0
0.3
