Appendix A Technical Specifications - Magtek DynaFlex II Go Installation And Operation Manual

Appendix A - Technical Specifications
Appendix A
ISO 7810, ISO 7811, AAMVA
ISO/IEC 7816-1, 2, 3, & 4 Identification Cards Integrated Circuits with Contacts
EMV ICC Specifications for Payment Systems Version 4.3d, L1 Contact and Version 4.4a, L2 Contact
EMV Contactless Level 1 Version 3.1a
MasterCard TQM
MCL v3.1.4, payWave v2.2c, Expresspay 4.1, D-PAS Terminal Payment Application v2.0
PCI PTS POI v6.2 SCR
DUKPT TDES, AES 128 DUKPT
FCC Part 15 Low Power Transceiver, RX verified per FCC Title 47 Part 15 Subclass C
UL/CSA/IEC 62368-1, 2nd edition
CE Certified
CE Safety: IEC 62368-1: 2014
Canada ISED Certified
AS/NZS CISPR 32 (2013), AS/NZS 4268 Table 1, Row 59 DTS 2400-2483MHz SRD (802.11), and
AS/NZS 4268 (2017) Table 1, Row 43 13.553-13.567MHz (contactless reader)
RoHS Compliant the Electrical and Electronic Equipment (EEE) Reduction of Hazardous Substances
(RoHS) European Directive 2002/95/EC
California Proposition 65 (California)
IPC-A-610 Class II Assembly
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
Universal Serial Bus Specifications 1.1, 2.0
AES, SHA-256
Bluetooth Core Specification 4.2
Dimensions (L x W x H):
Weight
Supported Mounting Options:
Magnetic Stripe Reader:
Magnetic Stripe Decoding:
Magnetic Swipe Speeds:
EMV Contact Reader:
EMV Contactless Reader:
DynaFlex II Go| EMV Contactless/NFC Card Reader | Installation and Operation Manual
Technical Specifications
DynaFlex II Go Products Technical Specifications
Reference Standards and Certifications
Physical Characteristics
2.76 in. x 2.57 in. x .79 in. (70.10mm x 65.3mm x20.1mm)
DynaFlex II Go = 3.17 oz. (90g)
DynaFlex II Go BCR = 3.24 oz. (92g)
Mounting to host via external clip or embedded lanyard
Reader Characteristics
Three track bidirectional encrypting reader with MagnePrint
Financial (ISO Type B), AAMVA, or Other
6 inches per second to 60 inches per second
EMVCo L1 and L2 Contact Reader
EMVCo L1 and L2 Contactless Reader
D-PAS, PayPass/MCL, payWave, Expresspay
Mobile wallets including but not limited to Apple Pay, Google Pay,
Samsung Pay
Page 45 of 55 (D998200595-100)
