Appendix A - Technical Specifications
Appendix A
Magnetic stripe: 3 Track Read Data
Identification Cards Financial Transaction Cards (ISO 7813)
AAMVA
Identification Cards Integrated Circuits with Contacts (ISO 7816)
EMV ICC Specifications for Payment Systems Ver 4.3, L1 Contact and L2 Contact
Encryption: TDEA (3DES)-CBC using DUKPT
IPC-A-610 Class II Assembly
Ingress Protection: IP-30 per ANSI/IEC 60529-2004
FCC Title 47 Part 15 Class B
CE Level B EMC
CE Safety
UR/CUR UL Recognized
California Proposition 65 (California)
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
Universal Serial Bus Specification 2.0
TQM Label Certified
Dimensions (L x W x H):
Weight
Supported Mounting Options:
Magnetic Stripe Reader:
Magnetic Stripe Decoding:
Acceptable Swipe Speeds:
Chip Card Reader:
Status Indicators:
Display Type:
Display Size (viewable area):
Display Resolution:
eDynamo| Secure Card Reader Authenticator | Installation and Operation Manual
Technical Specifications
eDynamo Technical Specifications
Reference Standards and Certifications
Physical Characteristics
2.45 in. x 1.52 in. x 0.97 in. (62.2 mm x 38.7 mm x 24.7 mm)
Handheld: 2.2 oz. (60 g)
With docking station: 4.3 oz. (120 g)
Handheld
Countertop with optional docking station micro-suction pads
Card Read Characteristics
Bidirectional 3 track non-encrypting IntelliHead magnetic stripe reader
(MSR) with MagnePrint
Financial (ISO Type B), AAMVA, or Other
6 inches per second to 60 inches per second
EMVCo L1 and L2 Contact Reader
User Interface Characteristics
General Status LED (Red/Green/Amber)
Bluetooth Status LED (Blue)
Not Applicable
Not Applicable
Not Applicable
