Magtek DynaFlex II Go Installation And Operation Manual page 46

Appendix A - Technical Specifications
Barcode Reader:
User Interface Characteristics
Status Indicators:
Display Type:
Keypad:
Security Characteristics
Certifications:
Tamper Protection:
Electrical Characteristics
Power Inputs:
Power Outputs:
Rechargeable Battery Type:
Voltage Requirements:
Current Requirements:
Data Storage:
Communication
Characteristics
Wired Connection Types:
Wireless Connection Types:
RF Exposure:
Software Characteristics
Tested Operating System(s):
DynaFlex II Go| EMV Contactless/NFC Card Reader | Installation and Operation Manual
DynaFlex II Go Products Technical Specifications
Barcode Media: Labels, paper, smartphone / computer displays
Barcode Types: QR Codes, Linear Barcodes, UPC-A, UPC-E, Code
128, PDF417 / Data Matrix, Aztec, etc.
Field Of View 31.5° total vertical sweep, 42° total horizontal sweep,
perpendicular to device face
Depth Of Field 1.2 in. (30mm) to 13.8 in. (350mm)
Integrated white indicator LED
4 Monochrome Green LEDs
1 Integrated white indicator LED for BCR
Not Applicable
Not Applicable
PCI PTS POI v6.2 Certified Secure Card Reader (SCR)
The enclosure and associated electronics form a Tamper Resistant
Security Module (TRSM) where attempts to penetrate or modify the
unit cause all cryptographic keys to be cleared or rendered unusable.
USB powered via USB-C receptacle
None
Lithium-Ion Polymer (LiPo)
5 VDC
800 mA recommended
Not Applicable
USB-C, compatible with USB 1.1, USB 2.0, USB 3.0 preferred
Vendor-defined USB Human Interface Device (HID) data format
None
Exempt from SAR requirements due to radiated power substantially
below regulatory thresholds.
USB Hosts: Windows 10, Android 4.4.2 and above
Page 46 of 55 (D998200595-100)
