7 - Introduction to User Interface
5. When the host is pairing with DynaFlex II GO, LED 4 will remain off and LED 2 will power
on, indicating the pair is processing.
6. The device will return to Power On status if pairing Succeeds or Fails. LED 2 will power off
and LED 1 will remain powered on.
.
DynaFlex II Go| EMV Contactless/NFC Card Reader | Installation and Operation Manual
Figure 7-10 - Activate BLE Pairing Mode
Figure 7-11 - Bluetooth LE Pair Processing
Figure 7-12 - Pairing Successful/Failed
Page 28 of 55 (D998200595-100)
