7 - Introduction to User Interface
7.7

LED Behavior: Errors, Timeouts, and Canceled Transactions

The table below contains LED behavior related to errors, timeouts, and canceled transactions. If the
device is exhibiting LED behavior not previously mentioned, it may be contained in this section.
Table 7-2 - LED Behavior for Errors, Timeouts, and Canceled Transactions
Device Model
DynaFlex II Go BCR
Connected via USB
DynaFlex II Go BCR
Connected via BLE
DynaFlex II Go MSR
Connected via USB
DynaFlex II Go| EMV Contactless/NFC Card Reader | Installation and Operation Manual
Figure 7-27 - LED ON/OFF State
Figure 7-28 - BCR Light ON/OFF State
Error LED Behavior
LED 1,2 ON – BCR ON
> LED1,2 ON, BCR
OFF + Double Beeps
> Ready
LED 1,2 ON – BCR ON
> LED1,2 ON, BCR
OFF + Double Beeps
> Ready
LED 1,2 ON
> LED1,2,3 OFF – LED
4 ON + Double beeps
Page 35 of 55 (D998200595-100)
Timeout LED Behavior Cancel LED Behavior
LED1,2,3 OFF – LED 4
BCR ON + Double
Beeps
LED1,2,3 OFF – LED 4
BCR ON + Double
Beeps
LED1,2,3 OFF – LED4
ON + Double beeps
LED 1,2 ON – BCR ON
> LED1,2 ON – BCR
OFF + Double Beeps
> Ready
LED 1,2 ON - BCR ON
> LED1,2 ON - BCR
OFF + Double Beeps
> Ready
LED 1,2 ON
> LED1,2 ON + Double
Beeps
> Ready
