ADSP-BF538F EZ-KIT Lite Hardware Reference

JTAG Connector (ZP4)

The JTAG header is the connecting point for a JTAG in-circuit emulator
pod. When an emulator connects to the JTAG header, the USB debug
interface is disabled.
Pin 3 is missing to provide keying. Pin 3 in the mating connector
should have a plug.
When using an emulator with the EZ-KIT Lite board, follow the
connection instructions provided with the emulator.

SPORT0 and SPORT1 Connectors (P6 and P7)

The pinout of the
P6
EZ-KIT Lite Schematic" on page
Part Description
IDC header
IDC socket

PPI Connector (P8)

The pinout of the
P8
Lite Schematic" on page
Part Description
IDC header
IDC socket
ADSP-BF538F EZ-KIT Lite Evaluation System Manual
and connectors can be found in
P7
B-1.
Manufacturer
FCI
Mating Connector
DIGI-KEY
connector can be found in
B-1.
Manufacturer
FCI
Mating Connector
DIGI-KEY
"ADSP-BF538F
Part Number
68737-434HLF
S4217-ND
"ADSP-BF538F EZ-KIT
Part Number
68737-440HLF
S4220-ND
2-23
