Ref. Qty. Description
61 71 0.01UF 16V 10%
0402
62 28 10K 1/16W 5%
0402
63 1 4.7K 1/16W 5%
0402
64 5 0 1/16W 5% 0402
65 4 1.2K 1/16W 5%
0402
66 6 33 1/16W 5% 0402
67 2 18PF 50V 5% 0805
68 2 100MA CMDSH-3
SOD-323
69 2 100UF 10V 10% C
70 2 1000PF 50V 5%
0402
71 9 0.1UF 16V 10%
0603
72 2 33PF 50V 5% 0603
ADSP-BF538F EZ-KIT Lite Evaluation System Manual
ADSP-BF538F EZ-KIT Lite Bill Of Materials
Reference Manufacturer
Designator
C1-27,C30-46, AVX
C91-93,C95-97,
C103-104,
C107-109,C132,
C137,C141,
C143-147,
C202-205,C211,
C225-227
R2-3,R5,R7,R9, VISHAY
R12-16,R24-25,
R77,R79-80,
R84-85,R87-90,
R162,R169,
R171-172,R176,
R179,R182,R216
R4 VISHAY
R120-121,R163, PANASONIC
R207,R215
R10,R67-68,R175 PANASONIC
R1,R8,R54, PANASONIC
R75-76,R119
C28-29 AVX
D1-2 CENTRAL
SEMI
CT3,CT5 KOA
C127-128 AVX
C64,C72-74, AVX
C87-89,C125,
C130
C118,C122 PANASONIC
Part Number
0402YC103KAT2A
CRCW040210K0FKED
CRCW04024K70JNED
ERJ-2GE0R00X
ERJ-2GEJ122X
ERJ-2GEJ330X
08055A180JAT2A
CMDSH-3-E3
TMC1ACTTE107K
04025C102JAT2A
0603YC104KAT2A
ECJ-1VC1H330J
A-5
