Connectors
JTAG Connector (ZP4)
The JTAG header (
emulator pod. When an emulator is connected to the JTAG header, the
USB debug interface is disabled.
Pin 3 is missing to provide keying. Pin 3 in the mating connector should
have a plug.
When using an emulator with the EZ-KIT Lite board, follow the
connection instructions provided with the emulator.
Part Description
14-pin IDC header (
Audio Connectors (J4 and J5)
There are two 3.5 mm stereo audio jacks: one input and one output.
Part Description
3.5 mm stereo jack (
3.5 mm stereo plug to 3.5 mm stereo
cable
2-14
www.BDTIC.com/ADI
) is the connecting point for a JTAG in-circuit
ZP4
Manufacturer
)
FCI
P8
Manufacturer
and
)
A/D ELECTRONICS
J4
J5
Mating Connector
RADIO SHACK
ADSP-21160 EZ-KIT Lite Evaluation System Manual
Part Number
68737-414HLF
Part Number
ST-323-5
42-2387A
