Ref. Qty. Description
88 4 5.49K 1/10W 1%
0603
89 2 3.32K 1/10W 1%
0603
90 2 1.65K 1/10W 1%
0603
91 2 49.9K 1/10W 1%
0603
92 2 604.0 1/10W 1%
0603
93 2 90.9K 1/10W 1%
0603
94 2 0.1 1/10W 1% 0603 R61,R148
95 2 10.0K 1/10W 1%
0603
96 8 5.76K 1/10W 1%
0603
97 4 120PF 50V 5%
0603
98 12 100PF 50V 5%
0603
99 4 1000PF 50V 5%
0603
100 2 62.0 1/10W 1%
0603
101 4 220PF 50V 5%
0603
102 2 680PF 50V 5%
0603
ADSP-BF538F EZ-KIT Lite Evaluation System Manual
ADSP-BF538F EZ-KIT Lite Bill Of Materials
Reference Manufacturer
Designator
R42-43,R46-47 DIGI-KEY
R44,R48 DIGI-KEY
R45,R49 DIGI-KEY
R38,R41 DIGI-KEY
R50-51 DIGI-KEY
R58,R63 DIGI-KEY
PANASONIC
R159-160 DIGI-KEY
R17-19,R21-22, DIGI-KEY
R28,R34-35
C47-49,C71 AVX
C52-54,C61,C65, AVX
C68,C75,C77,
C81,C85,C94,
C106
C66-67,C69-70 PANASONIC
R65-66 DIGI-KEY
C82,C86,C117, PANASONIC
C124
C80,C83 PANASONIC
Part Number
311-5.49KHRTR-ND
311-3.32KHRTR-ND
311-1.65KHRTR-ND
311-49.9KHRTR-ND
311-604HRTR-ND
311-90.9KHRTR-ND
ERJ-3RSFR10V
311-10.0KHRTR-ND
311-5.76KHRTR-ND
06035A121JAT2A
06035A101JAT2A
ECJ-1VC1H102J
311-62.0HRTR-ND
ECJ-1VC1H221J
ECJ-1VC1H681J
A-7
