Ref. Qty. Description
30 5 DIP4 SWT018
31 1 DB9 9PIN
CON038
32 2 RJ11 4PIN
CON039
33 1 DIP2 SWT020
34 3 IDC 2X1 IDC2X1
35 1 IDC 3X1 IDC3X1
36 2 IDC 5X2 IDC5X2
37 1 IDC 7X2 IDC7X2
38 4 IDC 10X2
IDC10X2
39 2 IDC 17X2
IDC17X2
40 1 IDC 20X2
IDC20X2
41 1 2.5A RESETABLE
FUS001
42 3 IDC
2PIN_JUMPER_SH
ORT
43 2 3.5MM
STEREO_JACK
CON001
44 3 IDC 3X2 IDC3X2
45 2 IDC 6X2 IDC6X2
46 5 YELLOW LED001
47 1 0.1UF 50V 10%
0805
ADSP-BF538F EZ-KIT Lite Evaluation System Manual

ADSP-BF538F EZ-KIT Lite Bill Of Materials

Reference Manufacturer
Designator
SW2,SW4-6, ITT
SW14
J6 NORCOMP
J5,J11 TYCO
SW3 C&K
JP6,JP8-9 FCI
JP1 FCI
P11-12 FCI
ZP4 FCI
P3-4,P9-10 FCI
P6-7 FCI
P8 FCI
F1 RAYCHEM
SJ5-7 DIGI-KEY
J9-10 A/D ELEC-
TRONICS
P13-15 SULLINS
P1-2 FCI
LED2-6 PANASONIC
C116 AVX
Part Number
TDA04HOSB1
191-009-213-L-571
5558872-1
TDA02H0SB1
90726-402HLF
90726-403HLF
68737-410HLF
68737-414HLF
68737-420HLF
68737-434HLF
68737-440HLF
SMD250F-2
S9001-ND
ST-323-5
GEC03DAAN
68737-412HLF
LN1461C
08055C104KAT
A-3
