• Universal asynchronous receiver/transmitter (UART)
ADM3202 RS-232 line driver/receiver
DB9 female connector
• LEDs
10 LEDs: 1 power (green), 1 board reset (red), 1 USB (red),
5 general-purpose (amber), and 1 USB monitor (amber)
• Push buttons
5 push buttons: 1 reset, 4 programmable flags with
debounce logic
• Expansion interface
All processor signals
• Other features
JTAG ICE 14-pin header
The EZ-KIT Lite board has flash memory with a total of 4 MB. Flash
memory can be used to store user-specific boot code, allowing the board
to run as a stand-alone unit. For more information, see
on page 1-10. The board also has 64 MB of SDRAM, which can be used
by the user at runtime.
interfaces with the audio circuit, facilitating development of audio
SPORT0
signal processing applications.
to an off-board connector for communication with other serial devices.
For more information, see
The UART of the processor connects to an RS-232 line driver and a DB9
female connector, providing an interface to a PC or other serial device.
ADSP-BF538F EZ-KIT Lite Evaluation System Manual
, , and
SPORT0 SPORT1
"SPORT0 Interface" on page
"Flash Memory"
also interface
SPORT2
2-4.
