Chapter 2: External Connectors Pinout Description

C 2: e
haPter xternal

Power Button

Connector number: 1
Pin Definition
1 GND
3 PWRBT_IN#
A1 LED_A
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
C
onneCtors
Pin Definition
2 PWRBT_IN#
4 GND
C1 LED_C
P d
Inout esCrIPtIon

LED Indicators (WLAN, WWAN, GPS and SSD)

Connector number: 2
WLAN WWAN
GPS SSD
LED
WLAN Blink: Active
WWAN Blink: Active
GPS Light On: Active
SSD Blink: Active
10
Description
