Appendix E: Power Consumption

a e: P
PPendIx
OS: Windows 10
Burn-in Software: Version 6.0
Device:
Idle: Into OS (SSD) + Display (VGA) + All module not link and not transmit +
mSATA + Keyboard/Mouse.
Full: Into OS (SSD) + Display (VGA) + All module only 3G link player video +
ping external net + mSATA + Keyboard/Mouse + headphone + Run burn in
+ USB device trans + CAN trans + COM trans + GPS link.
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
C
ower onsumPtIon
Device
Idle State
Burn-in Mode
Full State
(VTC 1021)
Full State + Loading
Idle State
Burn-in Mode
(VTC 1021 Full State
with PoE)
Full State + Loading
62
Result
Test Case
Current(A)
12V 0.96
24V 0.53
36V 0.38
12V 2.04
24V 1.06
36V 0.72
12V 4.86
24V 2.33
36V 1.60
12V 1.01
24V 0.57
36V 0.42
12V 2.01
24V 1.02
36V 0.70
12V 12.22
24V 5.02
36V 3.33
VTC 1021 Series User Manual
Watt(W)
11.52
12.72
13.68
24.48
25.44
25.92
58.32
55.92
57.6
12.12
13.68
15.12
24.12
24.48
25.2
146.64
120.48
119.88
